LG MCD202 - Front; Back Panel

4
1. DISPLAY WINDOW
2. •
1/
]
(POWER) button
• Z OPEN/CLOSE button
3. • XDSS/MP3 OPT. button
• XTS - PRO button
4. • USB (OPTIONAL)/DEMO button
• USB connector (OPTIONAL)
• PHONES (HEADPHONE JACK)
: 3.5mm
5. • TUNER button
• AUX button
6. Z PUSH EJECT position - TAPE 1
7. Z PUSH EJECT position - TAPE 2
8. • TUNING (-/+) buttons
bbbb
/
BBBB
(REWIND/FAST FORWARD)
buttons
.
bbbb
/
BBBB
> (CD SKIP/SEARCH)
buttons
• PRESET (-/+) buttons
FORWARD PLAY (
BB
) button
• x STOP button
9. • CD button
• TAPE button
10. • CLOCK button
• TIMER button
• RDS(OPTIONAL)/SET/CD
[]
button
• EQ. button
• CD SYNC./DUBB/ST./MONO button
• REC/
[]
button
• VOLUME CONTROL KNOB
11.
DISC SELECT (DISC1, DISC2, DISC3) buttons
12.
DISC TRAY
13. AM/FM ANTENNA TERMINAL
14. AUX IN (AUXILIARY INPUT) connector
15. POWER CORD
16. SPEAKER TERMINAL
Front / Back Panel
1
2
3
4
5
6
12
11
10
9
8
7
16
13
14
15
