25
Appendix
7
Appendix
7
Appendix
Specifications
General
Power supply Refer to main label.
(Mexico only : 120 V ~ 60 Hz)
Power consumption MCV905 : 180 W, MCT705 : 160W,
MCD605 : 140 W
Net Weight MCV905 : 6.69 kg, MCT705 : 6.67 kg
MCD605 : 6.45 kg
External dimensions (W x H x D) 280 x 377 x 354 mm
Bus Power Supply (USB) DC 5 V 500 mA
Operating conditions Temperature 5 °C to 35 °C,
Operation status: Horizontal
Operating humidity 5 % to 85 %
Laser Semiconductor laser, wavelength 650 nm
Tuner FM/AM [MW]
FM Tuning Range 87.5 to 108.0 MHz
FM Intermediate Frequency 128 kHz
AM Tuning Range 522 to 1 620 kHz, 520 to 1 710 kHz or
522 to 1 710 kHz
AM Intermediate Frequency 45 kHz
Amplier
Output Power MCV905 : Front : 280 W + 280 W
MCV905 : Surround : 140 W + 140 W
MCV905 : Sub Woofer : 180 W + 180 W
MCT705 : Front : 280 W + 280 W
MCT705 : Sub Woofer : 180 W
MCD605 : Front : 280 W + 280 W
CD
Frequency Response 40 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
