Appendix
Specifications
General
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) Approx. 430.0 mm x 142.5 mm x 364.0 mm
Operation Temperature Range 5 °C - 40 °C
Operation Humidity Range 5 % - 80 % RH
Bus Power Supply (USB)
5 V 0 500 mA
Available Digital Input Audio Sampling
Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Available Digital Input Audio format
Dolby Audio™, PCM
• PCM does not support multi channel.
Input/Output
AUX (Portable in) 1.0 V (3.5 mm stereo terminal) × 1
OPTICAL IN 3.0 V (p-p), (optical audio connection terminal) × 1
HDMI IN (1/2/3) 19-pin (Type A, HDMI™ connection terminal) × 3
HDMI OUT d TV (ARC)
19-pin (Type A, HDMI™ connection terminal) × 1
Microphone (MIC IN) Sensitivity 20 mV (1 kHz), 6.3 mm jack
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplifier (RMS output)
Total 2300 W RMS
Front (L/R) 460 W RMS×2 (Impedance: 6 Ω, THD 20 %)
Surround (L/R) 230 W RMS×2 (Impedance: 12 Ω, THD 20 %)
Subwoofer 460 W RMS×2 (Impedance: 6 Ω, THD 20 %)
