GENERAL DATA
Specications − Vertical Air Handler NK Chassis
Table 9: Vertical / Horizontal (NK Frame) Air Handler Unit General Data.
Model No. ARNU423NKA4 ARNU483NKA4 ARNU543NKA4
Cooling Mode Performance
Capacity (Btu/h)
42,000 48,000 54,000
Max Power Input
1
(W)
366 366 366
L/M/H Power Input at Factory Default (W)
186 / 215 / 260 186 / 264 / 330 264 / 312 / 370
Heating Mode Performance
Capacity (Btu/h)
46,000 54,000 60,000
Max Power Input
1
(W)
366 366 366
L/M/H Power Input at Factory Default (W)
186 / 215 / 260 186 / 264 / 330 264 / 312 / 370
Entering Mixed Air
Cooling Max. (°F WB)
76 76 76
Heating Min. (°F DB)
2
59 59 59
Unit Data
Refrigerant Type
3
R410A R410A R410A
Refrigerant Control
EEV EEV EEV
Sound Pressure
4
dB(A) (H/M/L)
46 / 44 / 41 49 / 47 / 41 50 / 49 / 47
Net Unit Weight (lbs.)
165 165 165
Shipping Weight (lbs.)
181 181 181
Communication Cable
5
(No. x AWG)
2 x 18 2 x 18 2 x 18
Fan
Type
Sirocco Sirocco Sirocco
Motor
1 1 1
Housing
1 1 1
Motor/Drive
Brushless Digitally Controlled / Direct
Airflow Rate H/M/L (CFM)
Standard Mode
1,250 / 1,100 / 1,000 1,400 / 1,260 / 1,000 1,475 / 1,400 / 1,260
Airflow Rate H/M/L (CFM)
High Mode (Factory Set)
1,250 / 1,100 / 1,000 1,400 / 1,260 / 1,000 1,475 / 1,400 / 1,260
External Static Pressure (in. wg)
Standard Mode
0.3 0.3 0.3
External Static Pressure (in. wg)
High Mode (Factory Set)
0.5 0.5 0.5
Piping
Liquid Line (in., O.D.)
3/8 Brazed 3/8 Brazed 3/8 Brazed
Vapor Line (in., O.D.)
5/8 Brazed 5/8 Brazed 5/8 Brazed
Condensate Line (in., I.D.)
1 1 1
EEV: Electronic Expansion Valve
Power wiring is field supplied and must comply with the applicable local and national
codes.
This unit comes with a dry nitrogen charge.
Rated capacity is certified under AHRI Standard 1230. Ratings are subject to change
without notice. Current certified ratings are available at www.ahridirectory.org.
1
Max power input is rated at maximum setting value.
2
Low ambient performance with LGRED° heat technology is included in Multi V 5 Air
Source Units produced after February 2019.
3
Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or
destroy R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F)
under section 608 of CAA.
4
Sound Pressure levels are tested in an anechoic chamber under ISO Standard 3745.
5
All communication cable to be minimum 18 AWG, 2-conductor, twisted, stranded, shielded
and must comply with applicable local and national codes. Shield must be joined and
insulated throughout. Ensure the communication cable is properly grounded at the master
outdoor unit only. Do not ground the ODU-IDU communication cable at any other point.
