LG MULTI V ARNU073M1A4

29
Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Dimensions – Vertical Air Handler NJ Chassis
48-11/16
18
21-1/4
48-11/16
49-5/16
2-9/16
1-15/16
21-1/4
12-1/8
1-1/2
9-15/16
2-1/16
18 17
2-1/8
13
4-11/16
1-9/16
1-9/16
1-9/16 1-15/16
1-5/8
14-5/16
Unit: inches
Note: All measurements
have a tolerance of ±1/4 in.
Drain connection
for upflow application
Drain connection
for horizontal
application
Liquid pipe
Vapor pipe
7/8” Wiring
knockouts
7/8” Wiring
knockouts
1-11/16” Wiring
knockouts
Supply Air
opening
Return Air
opening
BOTTOM VIEW
TOP VIEW
SIDE VIEW
FRONT VIEW
17-1/2
20
