Installation
16 Indoor Unit
GND
Signal
12 V
LGAP Network System
MN
Master
Slave
Display Error Message
Master
FAU
Slave
FAU
Master
or
Master Master
Display Error Message
FAU
Standard Standard
FAU FAU
Standard Standard
FAU
* FAU : Fresh Air Intake Unit
Standard: Standard Indoor Unit
In case of connecting with standard indoor unit and Fresh Air Intake Unit, separate Fresh
Air
Intake Unit with standard units. (N, M ≤ 16) (Because setting temperature are different.)
Other than those, it is same with Group Control 1.
3. Group Control 3
Mixture connection with indoor units and Fresh Air Intake Unit
