How to Set E.S.P?
20 Indoor Unit
How to Set E.S.P?
Setting Value
Static Pressure(mmAq(Pa))
0 (0) 1 (10) 2 (20) 3 (29) 4 (39) 5 (49)
60 - - - - - -
65 5.03 - - - - -
70 5.60 4.85 - - - -
75 6.19 5.44 4.57 - - -
80 6.79 6.05 5.17 - - -
85 7.41 6.67 5.80 4.80 - -
90 8.05 7.31 6.43 5.44 - -
95 8.71 7.96 7.09 6.09 4.97 -
100 9.38 8.63 7.76 6.76 5.64 -
105 9.32 8.45 7.45 6.33 5.08
110 -
-
10.03 9.16 8.16 7.04 5.79
115 - - 9.88 8.88 7.76 6.51
120 - - - 9.62 8.50 7.25
125 - - - 10.38 9.26 8.01
130 - - - - 10.03 8.78
ARNU05GL4G4, ARNU07GL4G4, ARNU09GL4G4
Setting Value
Static Pressure(mmAq(Pa))
0 (0) 1 (10) 2 (20) 3 (29) 4 (39) 5 (49)
75 6.50 - - - - -
80 7.34 6.70 - - - -
85 8.20 7.55 6.69 - - -
90 9.07 8.43 7.56 6.47 - -
95 9.96 9.32 8.45 7.36 - -
100 10.87 10.22 9.36 8.27 6.96 -
105 11.79 11.15 10.28 9.19 7.89 6.35
110 12.73 12.09 11.22 10.14 8.83 7.30
115 13.69 13.05 12.18 11.09 9.78 8.25
120 14.67 14.02 13.16 12.07 10.76 9.23
125 15.66 15.01 14.15 13.06 11.75 10.22
130 16.67 16.02 15.16 14.07 12.76 11.23
135 - - 16.18 15.10 13.79 12.26
140 - - - 16.14 14.83 13.30
145 - - - - 15.89 14.36
ARNU12GL5G4, ARNU15GL5G4, ARNU18GL5G4 (Unit : CMM)
(Unit : CMM)
(Unit : CMM)
ARNU21GL6G4, ARNU24GL6G4
Setting Value
Static Pressure(mmAq(Pa))
0 (0) 1 (10) 2 (20) 3 (29) 4 (39) 5 (49)
85 10.19 - - - - -
90 12.18 10.97 10.70 - - -
95 13.81 12.34 12.19 - - -
100 15.16 13.69 13.38 10.71 - -
105 16.30 14.83 14.36 11.85 - -
110 17.31 15.85 15.23 12.86 10.97 -
115 18.27 16.80 16.07 13.82 11.93 -
120 19.26 17.79 16.93 14.80 12.91 10.49
125 20.34 18.87 17.89 15.88 13.99 11.57
130 21.60 20.13 19.01 17.14 15.25 12.83
135 - 21.64 20.36 18.66 16.76 14.35
140 - - 22.01 20.50 18.61 16.19
Note :
1. The above table shows the correlation between the air rates and E.S.P.
2. Please refer wired remote controller manual for E.S.P setting procedure.
