10.2 Selection of the best location
Indoor unit
Install the air conditioner in the location that satisfies the fol-
lowing conditions.
• The place shall easily bear a load exceeding four times the
indoor unit’s weight.
• Sufficient space should be available to inspect the unit as in
the figure shown on the right.
• The place where the unit is installed shall be leveled.
• The place shall be suitable for easy connection of the indoor
unit with the outdoor unit.
• The place where the unit is installed should not be affected
by electrical noise.
• The place where air circulation in the room will be good .
• There should not be any heat source or steam near the unit
Service space
Select an installation site where the following conditions are
satisfied and that meets your customer's approval.
• Where the floor is strong enough to bear the indoor unit
weight.
• Where the floor is not significantly inclined.
• Where nothing blocks the air passage.
• Where condensate can be properly drained.
• Where sufficient clearance for installation and maintenance
can be ensured.
• Where there is no possibility of flammable gas leakage.
• Where optimum air distribution can be ensured.
• Where piping between indoor and outdoor units is possible
within the allowable limit (Refer to the installation manual of
the outdoor unit.)
• Keep the indoor and outdoor unit, power cable and transmis-
sion wiring, at least 1m from TVs and radios, to prevent dis-
torted pictures and static.(Depending on the type and source
of the electrical waves, static may be heard even when more
than 1 m away.)
