10.2.1 Preparing work for installation
n SB/SC chassis
Chassis cover
Right
Indoor unit back side view
Tubing holder
Downwards
Left
Backwards
10.2 Connection of pipes and cables
h The feature can be changed according to type of
model.
3. Pull back the tubing holder.
4. Remove pipe port cover and positioning the tubing
1. Pull the screw cap at the bottom of the indoor unit
2. Remove the chassis cover from the unit by loosing 2
screws
Ø65
133
95
Right rear piping
Left rear piping
Installation Plate
Place a level on raised tab
Unit Outline
217
175
442 442
Ø65Ø65Ø65
SB chassis
Ø65
SC chassis
SV chassis
Ø65
Ø65Ø65Ø65
69
56
Right rear piping
Left rear piping
Installation PlateInstallation PlateInstallation Plate
Measuring Tape
Measuring Tape
Hanger
Place a level on raised tab
Unit Outline
207
105
460 570
Ø65
Installation Plate
Left rear piping Right rear piping
C
D
B
A
167 Unit Outline 167
Installation plate
The lower left and the right side of
Installation Plate
CAUTION : In case that the unit is
installed near the sea, the installation
parts may be corroded by salt. The
installation parts (and the unit)
should be taken appropriate anti-cor-
rosion measures.
Wall Mounted Unit (Standard) _ 29
10. Installation
Indoor unit
Indoor Units
CHASSIS
Distance (mm)
A B C D
SV
150 140 43 43
