10 _ Compact Model
Indoor Units
Units Power Supply IFM Input(W)
Model Type Hz Volts
Voltage Range
MCA MFA kW FLA Cooling Heating
50 220-240
Max:264
Min:198
60 220
Max:242
Min:198
8. Electric Characteristicss
Symbols:
MCA : Min, Circuit Amps(A)
MFA : Max. Fuse Amps(see note 5)
kW : Fan Motor Rated Output(kW)
FLA : Full Load Amps(A)
IFM : Indoor Fan Motor
Note :
1. Voltage range
Units are suitable for use on electrical systems where volt-
age supplied to unit terminals is not below or above the listed
range limits,
2.
Maximum allowable voltage unbalance between phases is 2%
3. MCA/MFA
MCA=1.25 x FLA
MFA≤ 4 x FLA
(Next lower standard fuse rating. Min. 15A)
4. Select wire size based on the MCA
5. Instead of fuse, use Circuit Breaker.
ARNU09GTR*4 TR 0.25 15 0.043 0.2 30 30
ARNU15GTR*4 TR 0.25 15 0.043 0.2 30 30
ARNU09GTR*4 TR 0.25 15 0.043 0.2 30 30
ARNU15GTR*4 TR 0.25 15 0.043 0.2 30 30
