Indoor unit
Ceiling Concealed Duct(Low Static) _ 13
Indoor Units
Heating capacity
6. Capacity Tables
Notes:
TC: Total Capacity(kW)
1. Capacity tables show the representative value of conditions which may occur.
2. is shown as reference. When selecting the outdoor units, avoid the out-
door air temperature range shown by
.
3. In accordance with operation limits of outdoor unit, applicable range of capac-
ity tables is different.
4. Refer to Capacity Correction Factorin the outdoor unit PDBfor the actual per-
formance data of each indoor unitand outdoor unit combination.
Capacity
Index
Outdoor air
temp.
DB(°C) WB(°C)
Indoor air temp. (DB, °C)
16 18 20 21 22 24
TC TC TC TC TC TC
kW kW kW kW kW kW
-24.8 -25.0 2.3 2.3 2.3 2.3 2.3 2.3
-21.8 -22.0 2.8 2.8 2.8 2.8 2.8 2.8
-19.8 -20.0 2.9 2.9 2.9 2.9 2.9 2.9
-18.8 -19.0 3.0 3.0 3.0 3.0 3.0 3.0
-16.7 -17.0 3.1 3.1 3.1 3.1 3.1 3.1
-14.7 -15.0 3.3 3.3 3.3 3.3 3.3 3.3
-12.6 -13.0 3.5 3.4 3.4 3.4 3.4 3.4
-10.5 -11.0 3.6 3.6 3.6 3.6 3.6 3.5
-9.5 -10.0 3.7 3.7 3.7 3.7 3.7 3.5
-8.5 -9.1 3.8 3.8 3.7 3.7 3.7 3.5
-7.0 -7.6 3.9 3.9 3.9 3.8 3.7 3.5
-5.0 -5.6 4.0 4.0 4.0 3.9 3.7 3.5
-3.0 -3.7 4.2 4.1 4.0 3.9 3.7 3.5
0.0 -0.7 4.3 4.1 4.0 3.9 3.7 3.5
3.0 2.2 4.4 4.3 4.0 3.9 3.7 3.5
5.0 4.1 4.5 4.3 4.0 3.9 3.7 3.5
7.0 6.0 4.5 4.3 4.0 3.9 3.7 3.5
9.0 7.9 4.5 4.3 4.0 3.9 3.7 3.5
11.0 9.8 4.5 4.3 4.0 3.9 3.7 3.5
13.0 11.8 4.5 4.3 4.0 3.9 3.7 3.5
15.0 13.7 4.5 4.3 4.0 3.9 3.7 3.5
-24.8 -25.0 2.9 2.9 2.9 2.9 2.9 2.9
-21.8 -22.0 3.5 3.5 3.5 3.5 3.5 3.5
-19.8 -20.0 3.7 3.7 3.7 3.7 3.7 3.6
-18.8 -19.0 3.8 3.7 3.7 3.7 3.7 3.7
-16.7 -17.0 3.9 3.9 3.9 3.9 3.9 3.9
-14.7 -15.0 4.1 4.1 4.1 4.1 4.1 4.1
-12.6 -13.0 4.3 4.3 4.3 4.3 4.3 4.3
-10.5 -11.0 4.5 4.5 4.5 4.5 4.5 4.4
-9.5 -10.0 4.6 4.6 4.6 4.6 4.6 4.4
-8.5 -9.1 4.7 4.7 4.7 4.7 4.7 4.4
-7.0 -7.6 4.8 4.8 4.8 4.8 4.7 4.4
-5.0 -5.6 5.0 5.0 5.0 4.8 4.7 4.4
-3.0 -3.7 5.3 5.1 5.0 4.8 4.7 4.4
0.0 -0.7 5.3 5.2 5.0 4.8 4.7 4.4
3.0 2.2 5.5 5.3 5.0 4.8 4.7 4.4
5.0 4.1 5.6 5.3 5.0 4.8 4.7 4.4
7.0 6.0 5.6 5.3 5.0 4.8 4.7 4.4
9.0 7.9 5.6 5.3 5.0 4.8 4.7 4.4
11.0 9.8 5.6 5.3 5.0 4.8 4.7 4.4
13.0 11.8 5.6 5.3 5.0 4.8 4.7 4.4
15.0 13.7 5.6 5.3 5.0 4.8 4.7 4.4
-24.8 -25.0 3.6 3.6 3.6 3.6 3.6 3.6
-21.8 -22.0 4.4 4.4 4.4 4.4 4.4 4.4
-19.8 -20.0 4.6 4.6 4.6 4.6 4.6 4.6
-18.8 -19.0 4.8 4.7 4.7 4.7 4.7 4.7
-16.7 -17.0 5.0 5.0 5.0 4.9 4.9 4.9
-14.7 -15.0 5.2 5.2 5.2 5.2 5.2 5.2
-12.6 -13.0 5.5 5.4 5.4 5.4 5.4 5.4
-10.5 -11.0 5.7 5.7 5.7 5.7 5.7 5.5
-9.5 -10.0 5.8 5.8 5.8 5.8 5.8 5.5
-8.5 -9.1 5.9 5.9 5.9 5.9 5.9 5.5
-7.0 -7.6 6.1 6.1 6.1 6.0 5.9 5.5
-5.0 -5.6 6.3 6.3 6.3 6.1 5.9 5.5
-3.0 -3.7 6.6 6.5 6.3 6.1 5.9 5.5
0.0 -0.7 6.7 6.5 6.3 6.1 5.9 5.5
3.0 2.2 6.9 6.7 6.3 6.1 5.9 5.5
5.0 4.1 7.0 6.7 6.3 6.1 5.9 5.5
7.0 6.0 7.1 6.7 6.3 6.1 5.9 5.5
9.0 7.9 7.1 6.7 6.3 6.1 5.9 5.5
11.0 9.8 7.1 6.7 6.3 6.1 5.9 5.5
13.0 11.8 7.1 6.7 6.3 6.1 5.9 5.5
15.0 13.7 7.1 6.7 6.3 6.1 5.9 5.5
3.6
4.5
5.6
