2 _ Console
Indoor Units
2. Specification
Notes:-
1. Capacities are based on the following conditions:
Cooling • Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
• Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
Heating • Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
• Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without prior notification
4. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics”
chapter should be considered for electrical work and design. Especially the power cable and circuit breaker
should be selected in accordance with that.
5. EEV : Electronic Expansion Valve
6. Anechoic chamber conversion value is measured at 1.5 m downward from unit centre.
The values depends on the ambient conditions and values are normally higher in actual operation.
Conversion Formula
kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
l/s = CMM x 1000/60
Type
Model Unit
Cooling Capacity kW
kcal/h
Btu/h
Heating Capacity kW
kcal/h
Btu/h
Casing
Dimensions Body mm
(W x H x D) inch
Coil Rows x Columns x FPI
Face Area m
2
Fan Type
Motor Output x Number W
Running Current A
Air Flow Rate(H/M/L) CMM
cfm
Drive
Motor type
Temperature Control
Sound Absorbing Thermal Insulation Material
Safety Device
Pipe Liquid Side mm(inch)
Connections Gas Side mm(inch)
Drain(OD/ID) mm
Net Weight Body kg(lbs)
Noise Level(Sound Press, 1.5m, H/M/L) dB(A)
Power Supply Ø, V, Hz
Refrigerant Control
Power cable mm
2
(CV)
Transmission Cable mm
2
(VCTF-SB)
Console
ARNU07GQAA4 ARNU09GQAA4
2.2 2.8
1,900 2,400
7,500 9,600
2.5 3.2
2,200 2,800
8,500 10,900
Galvanized Steel Plate Galvanized Steel Plate
700 x 600 x 210 700 x 600 x 210
27-9/16 x 23-5/8 x 8-1/4 27-9/16 x 23-5/8 x 8-1/4
19 x 2 x 19 19 x 2 x 19
- -
Turbo fan Turbo fan
48 x 1 48 x 1
0.3 0.3
6.7 / 5.9 / 4.8 6.7 / 5.9 / 4.8
236 / 209 / 170 236 / 209 / 170
Direct Direct
BLDC BLDC
Microprocessor, Microprocessor,
Thermostat for Thermostat for
cooling and heating cooling and heating
Foamed polystrene Foamed polystrene
Fuse Fuse
Ø6.35(1/4) Ø6.35(1/4)
Ø12.7(1/2) Ø12.7(1/2)
17/12.2 17/12.2
14.0(30.9) 14.0(30.9)
37 / 34 / 28 37 / 34 / 28
1, 220 - 240, 50 1, 220 - 240, 50
EEV EEV
1.5 x 3C 1.5 x 3C
1.0 ~ 1.5 x 2C 1.0 ~ 1.5 x 2C
