Installation Manual 63

ENGLISH

Main Unit PCB

Sub Unit PCB

7 Segments

(Shows setting status)

SW03M (DIP switch)

SW03M

(DIP switch)

LED

(Shows setting status)

Main unit and Sub unit PCB

Main unit and Sub unit PCB
