Outdoor units Information
Outdoor units Information
n Heat pump
n Combination Ration(50~200%)
Notes: * We can guarantee the operation only within 130% Combination.
If you want to connect more than 130% combination, please contact us and discuss the
requirement like below.
1) If the operation of indoor unit is more than 130%, the airflow is operated as low in the all
indoor units.
2) The number of () means the number of Max. connectable indoor units, when the connected
capacity of indoor units is in the table above.
Outdoor Number Connection Capacity
Single outdoor units 200%
Double outdoor units 160%
Triple outdoor units 130%
Power Supply: Outdoor Unit (3Ø, 380 - 415V, 50Hz/3Ø, 380V, 60Hz)
8 Outdoor Unit
Unit
System(HP)
Model
Product Charge kg
Max. Connectable No. of Indoor Units
Net Weight kg
lbs
Dimensions (WxHxD) mm
inch
Connecting Pipes Liquid Pipes[mm(inch)]
Gas Pipes[mm(inch)]
1 Outdoor unit
8 10 12
ARUN80LN3 ARUN100LN3 ARUN120LN3
ARUN80LN3 ARUN100LN3 ARUN120LN3
5.0 6.4 6.4
13(20) 16(25) 20(30)
190 x 1 240 x 1 240 x 1
418 x 1 529 x 1 529 x 1
(920 x 1,680 x 760) x 1 (920 x 1,680 x 760) x 1 (920 x 1,680 x 760) x 1
(36.2 x 66.1 x 29.9) x 1 (36.2 x 66.1 x 29.9) x 1 (36.2 x 66.1 x 29.9) x 1
9.52(3/8) 9.52(3/8) 12.7(1/2)
19.05(3/4) 22.2(7/8) 28.58(1 1/8)
Unit
System(HP)
Model
Product Charge kg
Max. Connectable No. of Indoor Units
Net Weight kg
lbs
Dimensions (WxHxD) mm
inch
Connecting Pipes Liquid Pipes[mm(inch)]
Gas Pipes[mm(inch)]
1 Outdoor Unit
14 16 18 20
ARUN140LN3 ARUN160LN3 ARUN180LN3 ARUN200LN3
ARUN140LN3 ARUN160LN3 ARUN180LN3 ARUN200LN3
7.0 7.0 7.5 9.0
23(35) 26(40) 29(45) 32(44)
260 x 1 260 x 1 315 x 1 325 x 1
573 x 1 573 x 1 694 x 1 716 x 1
(1,240 x 1,680 x 760) x 1 (1,240 x 1,680 x 760) x 1 (1,240 x 1,680 x 760) x 1 (1,240 x 1,680 x 760) x 1
(48.8 x 66.1 x 29.9) x 1 (48.8 x 66.1 x 29.9) x 1 (48.8 x 66.1 x 29.9) x 1 (36.2 x 66.1 x 29.9) x 1
12.7(1/2) 12.7(1/2) 15.88(5/8) 15.88(5/8)
28.58(1 1/8) 28.58(1 1/8) 28.58(1 1/8) 28.58(1 1/8)
