LG MULTI V IV ARUN072BTE4 User Manual

15
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
HEAT PUMP ELECTRICAL DATA
Nom.
Tons
Unit Model Nos.
Compressor (Comp.)
Condenser Fan
Motor(s)
MCA MOCP
Comp.
Qty.
Motor Amps
Fan
Qty.
Amps
Motor RLA (Ea.)
FLA (Ea.)
Frame Frame
1 2 3 1 2 3
Frame
1 2 3
Frame
1 2 3
Comp.
A
Comp.
B
Comp.
A
Comp.
B
Comp.
A
Comp.
B
6.0 ARUN072BTE4 1 17.0 - - - - - 1 4.0 - - 25.3 - - 40 - -
8.0 ARUN096BTE4 1 27.3 - - - - - 2 6.0 - - 40.1 - - 60 - -
10.0 ARUN121BTE4 1 27.4 - - - - - 2 6.0 - - 40.3 - - 60 - -
12.0 ARUN144BTE4 2 19.0 19.0 - - - - 2 6.0 - - 48.8 - - 60 - -
14.0 ARUN168BTE4 2 20.7 20.7 - - - - 2 6.0 - - 52.5 - - 70 - -
16.0 ARUN192BTE4 2 17.0 - 27.4 - - - 3 4.0 6.0 - 25.3 40.3 - 40 60 -
18.0 ARUN216BTE4 3 17.0 - 19.0 19.0 - - 3 4.0 6.0 - 25.3 48.8 - 40 60 -
20.0 ARUN240BTE4 3 27.3 - 19.0 19.0 - - 4 6.0 6.0 - 40.3 48.8 - 60 60 -
22.0 ARUN264BTE4 3 27.4 - 19.0 19.0 - - 4 6.0 6.0 - 40.3 48.8 - 60 60 -
24.0 ARUN288BTE4 4 19.0 19.0 19.0 19.0 - - 4 6.0 6.0 - 48.8 48.8 - 60 60 -
26.0 ARUN312BTE4 4 17.0 - 27.3 - 19.0 19.0 5 4.0 6.0 6.0 25.3 40.1 48.8 40 60 60
28.0 ARUN336BTE4 4 27.3 - 27.3 - 19.0 19.0 6 6.0 6.0 6.0 40.1 40.1 48.8 60 60 60
30.0 ARUN360BTE4 4 27.3 - 27.4 - 19.0 19.0 6 6.0 6.0 6.0 40.1 40.3 48.8 60 60 60
Table 7: 208-230V, 60Hz, 3-Phase Heat Pump Units.
For component model nos. see the specication tables on p.
9-11.
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOCP) is calculated as fol-
lows: (Largest motor FLA x 2.25) + (Sum of other motor FLA)
rounded down to the nearest standard fuse size.
Nom.
Tons
Unit Model Nos.
Compressor (Comp.)
Condenser Fan
Motor(s)
MCA MOCP
Comp.
Qty.
Motor Amps
Fan
Qty.
Amps
Motor RLA (Ea.)
FLA (Ea.)
Frame Frame
1 2 3 1 2 3
Frame
Frame
1 2 3
1 2 3
Comp.
A
Comp.
B
Comp.
A
Comp.
B
Comp.
A
Comp.
B
6.0 ARUN072DTE4
1 11.7 - - - - - 1 2.1 - - 16.7 - - 25 - -
8.0 ARUN096DTE4 1 16.5 - - - - - 2 2.6 - - 23.2 - - 35 - -
10.0 ARUN121DTE4 1 17.1 - - - - - 2 2.6 - - 24.0 - - 40 - -
12.0 ARUN144DTE4 2 12.9 12.9 - - - - 2 2.6 - - 31.6 - - 40 - -
14.0 ARUN168DTE4 2 13.9 13.9 - - - - 2 2.6 - - 33.9 - - 45 - -
16.0 ARUN192DTE4 2 11.7 - 17.1 - - - 3 2.1 2.6 - 16.7 24.0 - 25 40 -
18.0 ARUN216DTE4 3 11.7 - 12.9 12.9 - - 3 2.1 2.6 - 16.7 31.6 - 25 40 -
20.0 ARUN240DTE4 3 16.5 - 12.9 12.9 - - 4 2.6 2.6 - 23.2 31.6 - 35 40 -
22.0 ARUN264DTE4 3 17.1 - 12.9 12.9 - - 4 2.6 2.6 - 24.0 31.6 - 40 40 -
24.0 ARUN288DTE4 4 12.9 12.9 12.9 12.9 - - 4 2.6 2.6 - 31.6 31.6 - 40 40 -
26.0 ARUN312DTE4 4 11.7 - 16.5 - 12.9 12.9 5 2.1 2.6 2.6 16.7 23.2 31.6 25 35 40
28.0 ARUN336DTE4 4 16.5 - 16.5 - 12.9 12.9 6 2.6 2.6 2.6 23.2 23.2 31.6 35 35 40
30.0 ARUN360DTE4 4 16.5 - 17.1 - 12.9 12.9 6 2.6 2.6 2.6 23.2 24.0 31.6 35 40 40
Table 8: 460V, 60Hz, 3-Phase Heat Pump Units.
For component model nos. see the specication tables on p.
12-14.
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOCP) is calculated as fol-
lows: (Largest motor FLA x 2.25) + (Sum of other motor FLA)
rounded down to the nearest standard fuse size.
