HEAT RECOVERY ELECTRICAL DATA
Table 16: 208-230V, 60Hz, 3-Phase Heat Recovery Units.
Nom.
Tons
Unit Model Nos.
Compressor (Comp.)
Condenser Fan
Motor(s)
MCA MOCP
Comp.
Qty.
Motor Amps
Fan
Qty.
Amps
Motor RLA (Ea.)
FLA (Ea.)
Frame Frame
1 2 3 1 2 3
Frame
Frame
1 2 3
1 2 3
Comp.
A
Comp.
B
Comp.
A
Comp.
B
Comp.
A
Comp.
B
6.0 ARUB072BTE4 1
17.0 - - - - - 1 4.0 - - 25.3 - - 40 - -
8.0 ARUB096BTE4 2 27.3 - - - - - 2 6.0 - - 40.1 - - 60 - -
10.0 ARUB121BTE4 2 27.4 - - - - - 2 6.0 - - 40.3 - - 60 - -
12.0 ARUB144BTE4 2 19.0 19.0 - - - - 2 6.0 - - 48.8 - - 60 - -
14.0 ARUB168BTE4 3 20.7 20.7 - - - - 2 6.0 - - 52.5 - - 70 - -
16.0 ARUB192BTE4 3 17.0 - 27.4 - - - 3 4.0 6.0 - 25.3 40.3 - 40 60 -
18.0 ARUB216BTE4 3 17.0 - 19.0 19.0 - - 3 4.0 6.0 - 25.3 48.8 - 40 60 -
20.0 ARUB240BTE4 4 27.3 - 19.0 19.0 - - 4 6.0 6.0 - 40.3 48.8 - 60 60 -
22.0 ARUB264BTE4 4 27.4 - 19.0 19.0 - - 4 6.0 6.0 - 40.3 48.8 - 60 60 -
24.0 ARUB288BTE4 4 19.0 19.0 19.0 19.0 - - 4 6.0 6.0 - 48.8 48.8 - 60 60 -
26.0 ARUB312BTE4 5 17.0 - 27.3 - 19.0 19.0 5 4.0 6.0 6.0 25.3 40.1 48.8 40 60 60
28.0 ARUB336BTE4 5 27.3 - 27.3 - 19.0 19.0 6 6.0 6.0 6.0 40.1 40.1 48.8 60 60 60
30.0 ARUB360BTE4 5 27.3 - 27.4 - 19.0 19.0 6 6.0 6.0 6.0 40.1 40.3 48.8 60 60 60
Table 17: 460V, 60Hz, 3-Phase Heat Recovery Units.
Nom.
Tons
Unit Model Nos.
Compressor (Comp.)
Condenser Fan
Motor(s)
MCA MOCP
Comp.
Qty.
Motor Amps
Fan
Qty.
Amps
Motor RLA (Ea.)
FLA (Ea.)
Frame Frame
1 2 3 1 2 3
Frame
Frame
1 2 3
1 2 3
Comp.
A
Comp.
B
Comp.
A
Comp.
B
Comp.
A
Comp.
B
6.0 ARUB072DTE4
1 11.7 - - - - - 1 2.1 - - 16.7 - - 25 - -
8.0 ARUB096DTE4 1 16.5 - - - - - 2 2.6 - - 23.2 - - 35 - -
10.0 ARUB121DTE4 1 17.1 - - - - - 2 2.6 - - 24.0 - - 40 - -
12.0 ARUB144DTE4 2 12.9 12.9 - - - - 2 2.6 - - 31.6 - - 40 - -
14.0 ARUB168DTE4 2 13.9 13.9 - - - - 2 2.6 - - 33.9 - - 45 - -
16.0 ARUB192DTE4 2 11.7 - 17.1 - - - 3 2.1 2.6 - 16.7 24.0 - 25 40 -
18.0 ARUB216DTE4 3 11.7 - 12.9 12.9 - - 3 2.1 2.6 - 16.7 31.6 - 25 40 -
20.0 ARUB240DTE4 3 16.5 - 12.9 12.9 - - 4 2.6 2.6 - 23.2 31.6 - 35 40 -
22.0 ARUB264DTE4 3 17.1 - 12.9 12.9 - - 4 2.6 2.6 - 24.0 31.6 - 40 40 -
24.0 ARUB288DTE4 4 12.9 12.9 12.9 12.9 - - 4 2.6 2.6 - 31.6 31.6 - 40 40 -
26.0 ARUB312DTE4 4 11.7 - 16.5 - 12.9 12.9 5 2.1 2.6 2.6 16.7 23.2 31.6 25 35 40
28.0 ARUB336DTE4 4 16.5 - 16.5 - 12.9 12.9 6 2.6 2.6 2.6 23.2 23.2 31.6 35 35 40
30.0 ARUB360DTE4 4 16.5 - 17.1 - 12.9 12.9 6 2.6 2.6 2.6 23.2 24.0 31.6 35 40 40
For component model nos. see the specication tables on p.
41-43.
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOCP) is calculated as fol-
lows: (Largest motor FLA x 2.25) + (Sum of other motor FLA)
rounded down to the nearest standard fuse size.
For component model nos. see the specication tables on p.
44-46.
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOCP) is calculated as fol-
lows: (Largest motor FLA x 2.25) + (Sum of other motor FLA)
rounded down to the nearest standard fuse size.
