Combi.
Outdoor
Air Temp.
Indoor Air Temp. (°C, DB)
16.0 18.0 20.0 21.0 22.0 24.0
(°C,
DB)
(°C,
WB)
TC PI TC PI TC PI TC PI TC PI TC PI
50
-24.8 -25 14.10 5.31 13.30 5.40 12.50 5.10 12.10 4.82 11.70 4.55 10.90 4.30
-21.8 -22 14.10 5.37 13.30 5.07 12.50 4.79 12.10 4.53 11.70 4.28 10.90 4.04
-19.8 -20 14.10 5.14 13.30 4.85 12.50 4.59 12.10 4.33 11.70 4.10 10.90 3.87
-18.8 -19 14.10 5.03 13.30 4.74 12.50 4.48 12.10 4.24 11.70 4.01 10.90 3.79
-16.7 -17 14.10 4.78 13.30 4.51 12.50 4.27 12.10 4.03 11.70 3.82 10.90 3.61
-15 -15.9 14.10 4.61 13.30 4.35 12.50 4.12 12.10 3.89 11.70 3.69 10.90 3.48
-13.7 -15 14.10 4.45 13.30 4.19 12.50 3.97 12.10 3.76 11.70 3.56 10.90 3.36
-11.8 -13 14.10 4.23 13.30 3.99 12.50 3.78 12.10 3.57 11.70 3.40 10.90 3.20
-9.8 -11 14.10 4.01 13.30 3.78 12.50 3.58 12.10 3.39 11.70 3.23 10.90 3.04
-9.5 -10 14.10 3.98 13.30 3.75 12.50 3.55 12.10 3.36 11.70 3.20 10.90 3.01
-8.5 -9.1 14.10 3.87 13.30 3.64 12.50 3.45 12.10 3.27 11.70 3.12 10.90 2.93
-7 -7.6 14.10 3.70 13.30 3.48 12.50 3.31 12.10 3.14 11.70 2.99 10.90 2.81
-5 -5.6 14.10 3.49 13.30 3.28 12.50 3.13 12.10 2.96 11.70 2.82 10.90 2.66
-3 -3.7 14.10 3.28 13.30 3.09 12.50 2.94 12.10 2.78 11.70 2.66 10.90 2.51
0 -0.7 14.10 2.98 13.30 2.79 12.50 2.67 12.10 2.54 11.70 2.42 10.90 2.28
3 2.2 14.10 2.66 13.30 2.50 12.50 2.40 12.10 2.28 11.70 2.19 10.90 2.05
5 4.1 14.10 2.46 13.30 2.30 12.50 2.21 12.10 2.10 11.70 2.03 10.90 1.90
7 6 14.10 2.26 13.30 2.11 12.50 2.04 12.10 1.93 11.70 1.87 10.90 1.75
9 7.9 14.10 2.04 13.30 1.91 12.50 1.83 12.10 1.74 11.70 1.69 10.90 1.57
11 9.8 14.10 1.91 13.30 1.79 12.50 1.72 12.10 1.63 11.70 1.58 10.90 1.47
13 11.8 14.10 1.79 13.30 1.67 12.50 1.61 12.10 1.54 11.70 1.48 10.90 1.39
15 13.7 14.10 1.69 13.30 1.58 12.50 1.53 12.10 1.45 11.70 1.41 10.90 1.31
Note
■ TC: Total Capacity(kW), PI : Power Input(kW, Comp. + Outdoor fan motor)
■ Capacity tables show the average value of conditions which may occur.
Multi V i
7. Capacity Tables
Product Data
7-94
