ZRUM260LTE6
Category
Unit Specification
Major Minor
Classification
Chassis - UXB + UXA
Combination Unit (1) - ZRUM140LTE6
Combination Unit (2) - ZRUM120LTE6
Combination Unit (3) - -
Combination Unit (4) - -
Power Supply
Case 1 V, Phase, Hz 380 - 400 - 415, 3, 50
Limit Range of Voltage(Case 1) V 342 ~ 456
Case 2 V, Phase, Hz 380, 3, 60
Limit Range of Voltage(Case 2) V 342 ~ 418
Running Current by Voltage (Cooling,Rated) A 38.44 - 36.52- 35.20
Running Current by Voltage (Heating,Rated) A 26.47 - 25.14 - 24.23
Cooling Capacity Rated
kW 72.8
Btu/h 248,400
Heating Capacity
Rated
kW 72.8
Btu/h 248,400
Max
kW 81.9
Btu/h 279,500
Power Input(Cooling) Rated kW 23.53
Power Input(Heating) Rated kW 16.2
Efficiency
EER(Rated) W/W 3.09
COP(Rated) W/W 4.49
SEER Wh/Wh 8.25
SCOP Wh/Wh 5.08
Power Factor(Cooling/Heating) Rated - 0.93 / 0.93
Outdoor Fan
Type - Propeller fan
Air Flow Rate(High) m³/min (320 × 1) + (220 × 1)
Max. External Static Pressure Pa 80
Discharge direction(Side / Top) - Top
Outdoor Fan Motor
Type - BLDC
Drive - Direct
Output W x No. (900 × 2) + (1,200 × 1)
Compressor
Type - Hermetically Sealed Scroll
Piston Displacement cm³/rev 62.1 x 2
Number of Revolution rev./min 3,600 x 2
Motor Output W x No. 5,300 x 2
Starting Method - Inverter
Oil Type - FW68L(PVE)
Heat Exchanger
Type - Fin & Tube
No. - 2
Fin Type - Wide Louver Plus
Dimensions
Net(W x H x D) mm (1,240 x 1,745 x 760) x 1) + (930 x 1,745 x 760) x 1)
Shipping(W x H x D) mm (1,282 x 1,919 x 802) x 1) + (965 x 1,919 x 802) x 1)
Weight
Net kg (255 × 1) + (215 × 1)
Shipping kg (265 x 1) + (225 x 1)
Exterior
Color - Morning Gray / Dawn Gray
RAL (Classic) - RAL 7038 / RAL 7037
Protection Device
High Pressure Prevention - High pressure sensor / High pressure switch
Frost Prevention - O (Logical)
Discharge Tempreature Control - O (Logical)
Compressor/Fan Protection - Over-heat protection / Fan driver overload protector
Inverter Protection - Over-heat protection / Over-current protection
Multi V i
1. Specifications
Product Data
1-19
