Combi.
Outdoor
Air Temp.
Indoor Air Temp. (°C, DB)
16.0 18.0 20.0 21.0 22.0 24.0
(°C,
DB)
(°C,
WB)
TC PI TC PI TC PI TC PI TC PI TC PI
50
-19.8 -20 49.50 21.16 46.70 20.05 43.90 19.00 42.50 18.02 41.10 17.11 38.30 16.21
-18.8 -19 49.50 20.76 46.70 19.63 43.90 18.64 42.50 17.66 41.10 16.77 38.30 15.90
-16.7 -17 49.50 19.86 46.70 18.80 43.90 17.84 42.50 16.91 41.10 16.07 38.30 15.22
-15 -15.9 49.50 19.23 46.70 18.19 43.90 17.27 42.50 16.37 41.10 15.58 38.30 14.73
-13.7 -15 49.50 18.60 46.70 17.59 43.90 16.71 42.50 15.84 41.10 15.08 38.30 14.26
-11.8 -13 49.50 17.81 46.70 16.83 43.90 15.99 42.50 15.17 41.10 14.46 38.30 13.66
-9.8 -11 49.50 16.98 46.70 16.03 43.90 15.25 42.50 14.47 41.10 13.80 38.30 13.03
-9.5 -10 49.50 16.86 46.70 15.91 43.90 15.14 42.50 14.37 41.10 13.70 38.30 12.94
-8.5 -9.1 49.50 16.42 46.70 15.50 43.90 14.77 42.50 14.01 41.10 13.38 38.30 12.62
-7 -7.6 49.50 15.80 46.70 14.92 43.90 14.22 42.50 13.48 41.10 12.89 38.30 12.15
-5 -5.6 49.50 15.00 46.70 14.16 43.90 13.49 42.50 12.80 41.10 12.25 38.30 11.55
-3 -3.7 49.50 14.21 46.70 13.39 43.90 12.78 42.50 12.13 41.10 11.61 38.30 10.94
0 -0.7 49.50 13.00 46.70 12.23 43.90 11.71 42.50 11.11 41.10 10.67 38.30 10.03
3 2.2 49.50 11.81 46.70 11.08 43.90 10.62 42.50 10.09 41.10 9.72 38.30 9.11
5 4.1 46.90 10.16 44.10 9.51 41.20 9.11 39.80 8.63 38.30 8.32 35.50 7.76
7 6 44.10 8.66 41.30 8.05 38.50 7.72 37.00 7.31 35.50 7.05 32.70 6.53
9 7.9 41.30 7.17 38.50 6.66 35.50 6.34 34.10 6.01 32.70 5.79 29.70 5.33
11 9.8 38.50 6.12 35.50 5.66 32.60 5.40 31.10 5.09 29.70 4.89 26.70 4.49
13 11.8 35.40 5.22 32.50 4.83 29.60 4.59 28.00 4.32 26.60 4.15 23.60 3.79
15 13.7 32.30 4.49 29.40 4.13 26.40 3.91 24.90 3.69 23.40 3.53 20.30 3.22
Note
■ TC: Total Capacity(kW), PI : Power Input(kW, Comp. + Outdoor fan motor)
■ Advanced SLC : Providing better comfort and energy saving considering cooling load with both outdoor and indoor side and using temperature and
humidity dual sensing control.
■ Capacity tables show the average value of conditions which may occur.
Multi V i
7. Capacity Tables
Product Data
7-199
