Function
3.2 Discharge temperature control
Outdoor unit control
Indoor unit control
3.3 Inverter protection control
AC input current is inverter input current except constant speed compressor current(Noise filter passed current)
Emergency
SH control
System stop
103˚C (221˚F) < Tdis
115˚C (239˚F)
Tdis > 115˚C (239˚F)
Temperature range
EEV
Keep current control
98˚C (208˚F) < Tdis 103˚C (221˚F)
SH control
Tdis 98˚C (208˚F)
Frequency down
System stop
105˚C (221˚F) < Tdis
112˚C (234˚F)
Tdis > 115˚C (239˚F)
Temperature range
Compressor
Pressure control
Max. limit
490 pulse
Subcooling EEV
Max. limit
300 pulse
Pressure control
10 pulse open /10sec
32A or more31A or more31A or lessCompressor current
29A or more27A or more26A or lessAC input current
System stopFrequency downNormal operation
Tdis 98˚C(208˚F)
Tdis >95˚C(203˚F)
3.4 Pressure switch
- Main has pressure sensing switch in series between compressor and power relay.
- The state of pressure sensing switch is normally on. It has small electric current from 220V AC. Never touch
the connecting terminal with hand nor short two wires directly.
