LG S75A1-D User Manual

2-26
ELECTRICAL TROUBLESHOOTING GUIDE
4. PAIRING BLUETOOTH
Check the connection of FFC.
Connect FFC.
YES
YES
YES
NO
L208 should be 3.3 V.
BT_RST should be high
(pin1 of CN202).
Check power.
Check micom (IC100).
Check MPEG (IC501).Change BT module.
NO
NO
NO
If it still
doesn’t work
