WCN603, DIP, 2P
(SWF)
CN901, Harness Cable,
10P
WCN602, SMD, 24P, B to B
(Wireless module)
Wireless
module
PN901, DIP, 2P
(Power Cord)
WOOFER SMPS PCB
WOOFER AMP
WCN601, DIP, 10P
WCN604, DIP, 2P
JK401,
Harness Cable,
2P
WOOFER
PAIRING KEY
WCN605, DIP, 3P
(LED CNT)
4-124-11
WIRING DIAGRAM
