Appendix 45
Appendix
6
Specifi cations
General
Power requirements Refer to main label on the rear panel.
Power consumption Refer to main label on the rear panel.
Dimensions (W x H x D) Approx. 430 x 60 x 243.5 mm (16.9 x 2.4 x 9.2 inches)
Net Weight (Approx.) 2.9 kg (6.4 lbs)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply (USB) DC 5 V
0
1 A
Inputs/Outputs
HDMI IN/OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
ANALOG AUDIO IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 2
DIGITAL IN (COAXIAL) 3 V (p-p), Coaxial jack x 1
PORT. IN
0.5 Vrms (
3.5 mm stereo jack)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Ampli er
Power output (4 Ω/ 3 Ω), (RMS), THD 10 %
Total 1100 W
Front 180 W x 2
Center 180 W
Rear 180 W x 2
Sub-Woofer 200 W (Passive)
