3) Disassembly of Top Cover
① Remove 2 screws attaching the back side of top
cover.
② Lift the top cover at the back of the washer
③ Push the Top Cover Assembly forward front side
until it doesn’t move.
④ Push each side of cabinet to remove from side
holders. If remove top cover from all of side holder,
lift the top cover.
⑤ Use the blade to push the left hinge out of the way
and to displace the hinge pin to remove the lid.
⑥ Remove 1 Screw, Cover, and Safety from the
Cabinet.
⑦ According to the environment, place the Top cover
on the floor at the side or back of the washer.
24
