Liberty Pumps LE50-Series User Manual

28 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

7000 Apple Tree Avenue

Bergen, NY 14416

Phone: (800) 543-2550

Fax: (585) 494-1839

www.libertypumps.com

IMPORTANT:

Prior to installation, record Model, Serial Number, and

Code Number from pump nameplate for future reference.

MODEL ______________________

SERIAL ______________________

CODE ______________________

INSTALLATION

DATE ______________________

©Copyright 2015 Liberty Pumps Inc. All rights reserved

Contents

1.) General Information

2.) The Basin

3.) Installation

4.) Electrical Service and Operation

5.) Maintenance and Troubleshooting

6.) Warranty

Installation Manual 7034000L

LE and LEH Series Sewage Pumps

Models

LE40-Series 4/10 HP

LE50-Series 1/2 HP

LE70-Series 3/4 HP

LE100-Series 1 HP

LEH100-Series 1 HP

LEH150-Series 1.5 HP

LEH200-Series 2 HP

*Do not throw away or lose this manual.
