Liebert GXT2-4500RT230 - Internal Battery Packs; Figure 2 GXT2, Rear View; Figure 3 Internal Battery Pack with Connector

Major Components
7
Figure 2 GXT2, rear view
3.2 Internal Battery Packs
The UPS has two internal battery packs behind a battery access door on the front of the unit. Each
pack is fitted with a connector to link to the UPS.
Figure 3 Internal battery pack with connector
Fans
External Battery
Connector
DB-9
Communication
Port
Removable Power
Distribution Box
Serial Card Slot
(SNMP, OCWEB, USB)
Relay Card Slot
REPO Connector
UPS Output
Circuit Breaker
Battery
Disconnect
