Major Components
8
3.3 Removable Power Distribution Box
The UPS arrives with a basic hardwire power distribution pack installed. This box always contains
the UPS input circuit breaker.
Optional versions may be available to replace the standard box for custom installations.
Figure 4
Power distribution boxes, basic, optional
NOTE
Hardwire and hardwire/receptacle boxes that include a manual bypass switch allow
AC power to continue to flow from the mains input to the load while the box is removed
from the UPS. For details, refer to 11.2 - AC Power Connections.
Basic Hardwire Power Distribution Box
PD-CEHDWR
Optional Hardwire Power Distribution
Box with Maintenance Bypass Switch
PD-CEHDWRBYP
