Major Components
7
3.0 MAJOR COMPONENTS
The Liebert GXT3 is composed of three major assemblies to provide easier handling, installation and
versatility.
3.1 Main Frame and Electronics
The cabinet is shipped with internal batteries installed and a basic, hardwire distribution box
attached and ready to install.
Figure 1 Liebert GXT3 5000VA and 6000VA, front view
Status Indicators
and Controls
Lower Bezel and
Battery Access
Door
Upper Bezel
10,000VA model’s front layout is
identical; the battery compartment
is larger.
