Liebert Hiflex - Page 100

Hiflex
96 All Versions
English
4SC A/W 4LC A/W 6SC A/W 8SC A/W
Air flow Available head Air flow Available head Air flow Available head Air flow Available head
[m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa]
0.275 469 0.375 373 0.375 433
0.300 438 0.400 345 0.400 414
0.325 406 0.425 318 0.425 395
0.350 370 0.450 291 0.450 378
0.375 332 0.475 266 0.475 362
0.380 324 0.500 241 0.500 348
0.400 290 0.525 216 0.525 334
0.425 247 0.530 211 0.550 321
0.450 202 0.550 192 0.575 308
0.475 159 0.575 166 0.600 293
0.500 119 0.600 139 0.625 276
0.525 83 0.625 109 0.640 265
0.549 50 0.650 76 0.650 256
0.550 49 0.668 50 0.675 233
0.572 16 0.675 38 0.700 207
0.575 11 0.699 0 0.725 177
0.581 0 0.750 144
0.775 108
0.800 71
0.814 50
0.825 33
0.846 0
11.3 - Reheating and humidity control (optional)
Electrical heating (and dehumidification system)
The electrical heaters can largely keep the correct
temperature with dry bulb. The elements are made of
aluminum with high efficiency fins to keep a low pow
er density on the surfaces. The ionization effects are
removed thanks to the low surface temperature of the
elements.
The stages of the electrical heaters are distributed on
the 3 phases to avoid balancing problems.
There are three steps, two contactors, temperature
electronic control of the ON-OFF type, safety ther
mostat with manual reset, magnetothermal switch against short circuits, harness protection against pos
sible casual contacts.
When the electrical heating is installed, the dehumidification system is operating as well, and the relevant
humidity sensor and indicator are provided (see "Humidification and dehumidification system" for the de
humidification function).
It is possible to install the electric heating matched with the hot gas or hot water reheating. In this case,
refer to the paragraph "Hot gas reheating" or "Hot water heating".
Heating capacity (400V/3ph/50Hz)
Models 4 6 8 5 7 9
3 steps, total power [kW] 4.5 4.5 4.5 9.0 9.0 9.0
2 steps [kW] 3.0 3.0 3.0 6.0 6.0 6.0
1 step [kW] 1.5 1.5 1.5 3.0 3.0 3.0
Hot gas reheating (and A/W/D/F/H unit optional dehumidification system)
Hiflex can be supplied with a reheating system using the heat that is normally sent to the condenser to
heat the air, saving energy. This system is activated during dehumidification (in fact, the relevant humidity
sensors and indicators are provided) when the temperature decreases under the set value: in this way
no additional energy is required for the reheating.
