8 - Aeraulic features
8.1 - Useful available heads
The air conditioners of the Hiflex series are supplied with electric fans sized for a useful head of 20 Pa for
the models under, 50 Pa for the models over.
When the pressure drop on the air side are higher or some ducts are provided on the air circuit, the air
flows vary as shown below.
The boldface numbers refer to the rated value.
Available heads - 50 Hz
4MU A
4SU A/W
5SU A/W
4LU A/W/C
5LU A/W
6SU A/W
7SU A/W
6LUA/W/C
7LU A/W
8SU A/W
9SU A/W
8LU A/W/C
9LU A/W
8LU /D/H/F
9LU /D/H/F
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
[m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa]
0.225 133 0.350 83 0.500 167 0.575 108 0.625 110 0.950 161 1.000 148 0.800 170
0.250 120 0.375 73 0.525 152 0.600 97 0.650 99 0.975 158 1.025 143 0.850 155
0.275 103 0.400 60 0.550 133 0.625 87 0.675 88 1.000 154 0.050 136 0.900 141
0.300 88 0.418 50 0.575 103 0.650 75 0.700 75 1.025 149 1.075 129 0.950 128
0.325 76 0.425 46 0.600 80 0.675 62 0.725 63 1.050 142 1.100 121 1.000 113
0.350 65 0.450 28 0.625 45 0.696 50 0.750 50 1.075 133 1.125 112 1.050 97
0.375 53 0.460 20 0.640 20 0.700 48 0.775 35 1.100 120 1.150 102 1.100 79
0.400 40 0.475 8 0.650 02 0.725 32 0.800 20 1.125 105 1.175 91 1.150 57
0.425 24 0.485 0 0.651 0 0.743 20 0.825 4 1.150 85 1.200 80 1.200 33
0.430 20 0.750 15 0.831 0 1.175 61 1.225 68 1.220 20
0.450 3 0.770 0 1.186 50 1.250 55 1.250 4
0.453 0 1.200 33 1.259 50
1.210 20 1.275 41
1.225 0 1.300 26
1.310 20
1.325 10
1.341 0
4MO A
4SO A/W
5SO A/W
4LO A/W/C
5LO A/W
6SO A/W
7SO A/W
6LO A/W/C
7LO A/W
8SO A/W
9SO A/W
8LO A/W/C
9LO A/W
8LO /D/H/F
9LO /D/H/F
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
[m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa]
0.225 99 0.375 64 0.450 163 0.475 139 0.575 124 0.875 115 0.975 106 0.800 142
0.250 78 0.400 50 0.475 151 0.500 130 0.600 114 0.900 109 1.000 99 0.840 126
0.275 52 0.425 38 0.500 136 0.525 121 0.625 103 0.925 104 1.025 91 0.880 112
0.300 27 0.450 15 0.525 118 0.575 100 0.650 91 0.950 99 1.050 82 0.920 98
0.325 4 0.467 0 0.550 95 0.600 89 0.675 79 0.975 93 1.075 72 0.960 84
0.330 0 0.575 68 0.625 78 0.700 67 1.000 86 1.100 61 1.000 69
0.589 50 0.675 52 0.725 53 1.025 77 1.125 50 1.040 55
0.600 35 0.678 50 0.730 50 1.050 67 1.150 37 1.050 50
0.623 0 0.700 36 0.750 39 1.075 53 1.175 23 1.080 38
0.725 20 0.775 24 1.080 50 1.200 9 1.120 18
0.750 2 0.800 8 1.100 37 1.216 0
0.754 0 0.812 0 1.125 18
1.145 0
