Liebert Hiflex - Page 32

Hiflex
28 all Versions
4SC A/W 4LC A/W 6SC A/W 8SC A/W
Air flow Available head Air flow Available head Air flow Available head Air flow Available head
[m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa]
0.300 81 0.375 191 0.375 164 0.800 107
0.325 68 0.400 159 0.400 157 0.825 99
0.350 55 0.425 130 0.425 151 0.850 91
0.360 50 0.450 111 0.450 145 0.875 84
0.375 41 0.475 99 0.475 139 0.900 76
0.400 25 0.500 82 0.500 132 0.925 67
0.425 6 0.525 56 0.525 124 0.950 58
0.530 50 0.550 115 0.970 50
0.550 23 0.575 106 0.975 48
0.600 94 1.000 37
0.625 82 1.025 24
0.650 68 1.050 8
0.675 54 1.075
0.680 50 1.100
0.700 38 1.125
0.725 21 1.150
0.750 3
Available heads - 60 Hz
4MU A
4SU A/W
5SU A/W
4LU A/W/C
5LU A/W
6SU A/W
7SU A/W
6LUA/W/C
7LU A/W
8SU A/W
9SU A/W
8LU A/W/C
9LU A/W
8LU /D/H/F
9LU /D/H/F
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
[m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa]
0.150 250 0.275 202 0.375 375 0.375 270 0.375 289 0.800 268 0.950 266 0.950 233
0.175 241 0.300 185 0.400 350 0.400 261 0.400 280 0.825 259 0.975 261 0.975 227
0.200 231 0.325 169 0.425 322 0.425 252 0.425 270 0.850 251 1.000 255 1.000 219
0.225 219 0.350 155 0.450 291 0.450 242 0.450 261 0.875 243 1.025 250 1.025 212
0.250 205 0.375 142 0.475 259 0.475 233 0.475 251 0.900 237 1.050 243 1.050 203
0.275 188 0.400 130 0.500 227 0.500 223 0.500 241 0.925 230 1.075 236 1.075 194
0.300 167 0.425 118 0.525 196 0.525 212 0.525 232 0.950 224 1.100 227 1.100 184
0.325 142 0.450 105 0.550 166 0.550 201 0.550 222 0.975 217 1.125 218 1.125 172
0.350 113 0.475 90 0.575 136 0.575 190 0.575 212 1.000 206 1.150 208 1.150 160
0.375 78 0.500 71 0.600 104 0.600 178 0.600 201 1.025 190 1.175 196 1.175 146
0.400 38 0.525 48 0.625 63 0.625 165 0.625 191 1.050 164 1.200 183 1.200 132
0.410 20 0.549 20 0.644 20 0.650 152 0.650 180 1.075 124 1.225 169 1.225 115
0.420 0 0.563 0 0.650 3 0.675 137 0.675 168 1.100 61 1.250 154 1.250 97
0.651 0 0.700 121 0.700 156 1.122 20 1.275 135 1.275 77
0.725 104 0.725 143 1.125 0 1.300 114 1.300 53
0.750 83 0.750 129 1.325 87 1.325 24
0.775 59 0.775 114 1.350 54 1.328 20
0.800 28 0.800 98 1.371 20 1.343 0
0.806 20 0.825 80 1.375 12
0.818 0 0.850 62 1.381 0
0.875 41
0.899 20
0.920 0
