Hiflex
29
all Versions
4MO A
4SO A/W
5SO A/W
4LO A/W/C
5LO A/W
6SO A/W
7SO A/W
6LO A/W/C
7LO A/W
8SO A/W
9SO A/W
8LO A/W/C
9LO A/W
8LO /D/H/F
9LO /D/H/F
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
Air flow
Avail
able
head
[m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa]
0.150 213 0.275 195 0.375 363 0.375 267 0.375 286 0.800 233 0.950 221 0.950 192
0.175 191 0.300 177 0.400 336 0.400 258 0.400 276 0.825 223 0.975 214 0.975 183
0.200 166 0.325 160 0.425 306 0.425 248 0.425 266 0.850 215 1.000 206 1.000 174
0.225 137 0.350 144 0.450 274 0.450 238 0.450 256 0.875 207 1.025 198 1.025 164
0.250 103 0.375 130 0.475 240 0.475 228 0.475 246 0.900 199 1.050 189 1.050 153
0.275 64 0.400 116 0.500 206 0.500 217 0.500 236 0.925 190 1.075 178 1.075 141
0.300 20 0.425 102 0.525 172 0.525 207 0.525 226 0.950 177 1.100 167 1.100 129
0.310 0 0.450 87 0.550 140 0.550 195 0.550 216 0.975 159 1.125 155 1.125 115
0.475 70 0.575 107 0.575 183 0.575 205 1.000 131 1.150 142 1.150 100
0.500 50 0.600 72 0.600 171 0.600 194 1.025 89 1.175 128 1.175 84
0.525 25 0.614 50 0.625 157 0.625 183 1.046 50 1.200 112 1.200 66
0.545 0 0.625 29 0.650 143 0.650 171 1.050 24 1.225 95 1.222 50
0.638 0 0.675 128 0.675 159 1.057 0 1.250 76 1.225 47
0.700 111 0.700 146 1.275 55 1.250 26
0.725 93 0.725 132 1.279 50 1.275 3
0.750 72 0.750 117 1.300 30 1.278 0
0.772 50 0.775 102 1.325 1
0.775 46 0.800 85 1.326 1
0.800 15 0.825 67
0.810 0 0.846 50
0.875 26
0.900 3
0.903 0
4SC A/W 4LC A/W 6sC A/W 8SC A/W
Air flow Available head Air flow Available head Air flow Available head Air flow Available head
[m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa]
0.275 155 0.375 304 0.375 233 0.800 171
0.300 130 0.400 269 0.400 219 0.825 158
0.325 105 0.425 230 0.425 204 0.850 146
0.350 80 0.450 189 0.450 189 0.875 134
0.375 56 0.475 145 0.475 173 0.900 122
0.381 50 0.500 101 0.500 156 0.925 108
0.400 32 0.525 56 0.525 139 0.950 91
0.425 7 0.528 50 0.550 121 0.975 68
0.432 0 0.550 13 0.575 102 0.990 50
0.557 0 0.600 82 1.000 36
0.625 62 1.020 0
0.639 50
0.650 40
0.675 16
0.692 0
The static pressure increase at the different air flows is indicated hereinafter for a proper calculation of the
required useful head. This increase must be taken into account if some optional devices are supplied.
