2.9 - Air control
All units are available in the three configurations shown below. The Hiflex Constant units are supply with
upward air flow (Over) only.
OVER
UNDER
2.10 - Dimensions and accessibility
The unit structures are made in three sizes with the following dimensions:
W D H
Size 4: 750 450 1950
Size 6: 750 600 1950
Size 8: 750 750 1950
Size 5: 1490 450 1950
Size 7: 1490 600 1950
Size 9: 1490 750 1950
Ordinary and special maintenance is easier thanks to the front access enabling the replacement of the
air filters, the intervention on the components of the refrigerating circuit - such as compressor, liquid re
ceiver, thermal expansion valve, refrigerant sight glass, drying filter - or on the fan, the humidifier, the elec
tric board, the electronic control, the electric heating elements.
The refrigerant, electric and hydraulic connections are placed on the lower part of the unit.
