Liebert Hiflex - Page 27

Hiflex
23All Versions
English
50 Hz / R 407C
STANDARD POWER SUPPLY OPTIONAL POWER SUPPLY
Model
FAN
1ph - 230V
COMPRESSOR
3ph - 400V
FAN
1ph - 230V
COMPRESSOR
3ph - 230V
Model
OA FLA LRA
operating
power
(kW)
OA FLA LRA
operating
power
(kW)
OA FLA LRA
operating
power
(kW)
OA FLA LRA
operating
power
(kW)
OPTIONAL R 407C
4PUA/W
(*)
1.4 2.1 3.1 0.3 6.8 10.9 45.0 1.5 1.4 2.1 3.1 0.3 6.8 10.9 45.0 1.5
4GUA/W 2.6 3.8 4.4 0.6 4.2 5.5 38.5 2.2 2.6 3.8 4.4 0.6 7.3 10.9 80.9 2.2
6PUA/W 2.6 4.5 8.0 0.4 4.8 6.3 43.5 2.5 2.6 6.5 5.5 0.4 8.3 12.4 91.4 2.5
6GUA/W 3.3 4.5 8.0 0.5 6.0 7.5 51.0 3.1 3.3 6.5 5.5 0.5 10.4 14.8 108.0 3.1
8PUA/W 4.5 7.0 7.1 0.9 6.0 7.5 51.0 3.1 4.5 7.0 7.1 0.9 10.4 14.8 108.0 3.1
8GUA/W 5.4 7.0 7.1 1.2 7.6 9.6 59.5 3.8 5.4 7.0 7.1 1.2 13.1 19.1 136.0 3.8
5PUA/W
(*)
1.4 x 2 2.1 x 2 3.1 x 2 0.6 6.8 x 2 10.9 x 2 45.0 x 2 3.0 1.4 x 2 2.1 x 2 3.1 x 2 0.6 6.8 x 2 10.9x 2 45.0x 2 3.0
5GUA/W 2.6 x 2 3.8 x 2 4.4 x 2 1.2 4.2 x 2 5.5 x 2 38.5 x 2 4.4 2.6 x 2 3.8 x 2 4.4 x 2 1.2 7.3 x 2 10.9x 2 80.9x 2 4.4
7PUA/W 2.6 x 2 4.5 x 2 8.0 x 2 0.8 4.8 x 2 6.3 x 2 43.5 x 2 5.0 2.6 x 2 6.5 x 2 5.5 x 2 0.8 8.3 x 2 12.4x 2 91.4x 2 5.0
7GUA/W 3.3 x 2 4.5 x 2 8.0 x 2 1.0 6.0 x 2 7.5 x 2 51.0 x 2 6.2 3.3 x 2 6.5 x 2 5.5 x 2 1.0 10.4x 2 14.8x 2 108.0x2 6.2
9PUA/W 4.5 x 2 7.0 x 2 7.1 x 2 1.8 6.0 x 2 7.5 x 2 51.0 x 2 6.2 4.5 x 2 7.0 x 2 7.1 x 2 1.8 10.4x 2 14.8x 2 108.0x2 6.2
9GUA/W 5.4 x 2 7.0 x 2 7.1 x 2 2.4 7.6 x 2 9.6 x 2 59.5 x 2 7.6 5.4 x 2 7.0 x 2 7.1 x 2 2.4 13.1x 2 19.1x 2 136.0x2 7.6
4POA/W
(*)
1.2 2.1 3.1 0.3 6.8 10.9 45.0 1.5 1.2 2.1 3.1 0.3 6.8 10.9 45.0 1.5
4GOA/W 2.5 3.8 4.4 0.5 4.2 5.5 38.5 2.2 2.5 3.8 4.4 0.5 7.3 10.9 80.9 2.2
6POA/W 2.2 4.5 8.0 0.3 4.8 6.3 43.5 2.5 2.2 6.5 5.5 0.3 8.3 12.4 91.4 2.5
6GOA/W 3.1 4.5 8.0 0.5 6.0 7.5 51.0 3.1 3.1 6.5 5.5 0.5 10.4 14.8 108.0 3.1
8POA/W 3.9 6.8 11.0 0.8 6.0 7.5 51.0 3.1 3.9 7.0 7.1 0.8 10.4 14.8 108.0 3.1
8GOA/W 4.7 6.8 11.0 1.1 7.6 9.6 59.5 3.8 4.7 7.0 7.1 1.1 13.1 19.1 136.0 3.8
4PCA/W
(*)
1.4 2.1 3.1 0.3 6.8 10.9 45.0 1.5 1.4 2.1 3.1 0.3 6.8 10.9 45.0 1.5
4GCA/W 2.4 3.8 4.4 0.6 4.2 5.5 38.5 2.2 2.4 3.8 4.4 0.6 7.3 10.9 80.9 2.2
6PCA/W 2.2 4.5 8.0 0.4 4.8 6.3 43.5 2.5 2.2 4.5 8.0 0.4 8.3 12.4 91.4 2.5
8PCA/W 4.2 6.8 11.0 0.8 6.0 7.5 51.0 3.1 4.2 6.8 11.0 0.8 10.4 14.8 108.0 3.1
5POA/W
(*)
1.2 x 2 2.1 x 2 3.1 x 2 0.6 6.8 x 2 10.9 x 2 45.0 x 2 3.0 1.2 x 2 2.1 x 2 3.1 x 2 0.6 6.8 x 2 10.9x 2 45.0x 2 3.0
5GOA/W 2.5 x 2 3.8 x 2 4.4 x 2 1.0 4.2 x 2 5.5 x 2 38.5 x 2 4.4 2.5 x 2 3.8 x 2 4.4 x 2 1.0 7.3 x 2 10.9x 2 80.9x 2 4.4
7POA/W 2.2 x 2 4.5 x 2 8.0 x 2 0.6 4.8 x 2 6.3 x 2 43.5 x 2 5.0 2.2 x 2 6.5 x 2 5.5 x 2 0.6 8.3 x 2 12.4x 2 91.4x 2 5.0
7GOA/W 3.1 x 2 4.5 x 2 8.0 x 2 1.0 6.0 x 2 7.5 x 2 51.0 x 2 6.2 3.1 x 2 6.5 x 2 5.5 x 2 1.0 10.4x 2 14.8x 2 108.0x2 6.2
9POA/W 3.9 x 2 6.8 x 2 11.0 x 2 1.6 6.0 x 2 7.5 x 2 51.0 x 2 6.2 3.9 x 2 7.0 x 2 7.1 x 2 1.6 10.4x 2 14.8x 2 108.0x2 6.2
9GOA/W 4.7 x 2 6.8 x 2 11.0 x 2 2.2 7.6 x 2 9.6 x 2 59.5 x 2 7.6 4.7 x 2 7.0 x 2 7.1 x 2 2.2 13.1x 2 19.1x 2 136.0x2 7.6
8GUD/H 5.0 6.8 11.0 1.1 7.6 9.6 59.5 3.8 5.0 6.8 11.0 1.1 13.1 19.1 136.0 3.8
8GOD/H 4.5 6.8 11.0 1.0 7.6 9.6 59.5 3.8 4.5 6.8 11.0 1.0 13.1 19.1 136.0 3.8
8GUF 5.0 6.8 11.0 1.1 8.6 9.6 59.5 4.7 5.0 6.8 11.0 1.1 14.9 19.1 136.0 4.7
8GOF 4.5 6.8 11.0 1.0 8.5 9.6 59.5 4.6 4.5 6.8 11.0 1.0 14.7 19.1 136.0 4.6
9GUD/H 5.0 x 2 6.8 x 2 11.0 x 2 2.2 7.6 x 2 9.6 x 2 59.5 x 2 7.6 5.0 x 2 6.8 x 2 11.0 x 2 2.2 13.1x 2 19.1x 2 136.0x2 7.6
9GOD/H 4.5 x 2 6.8 x 2 11.0 x 2 2.0 7.6 x 2 9.6 x 2 59.5 x 2 7.6 4.5 x 2 6.8 x 2 11.0 x 2 2.0 13.1x 2 19.1x 2 136.0x2 7.6
9GUF 5.0 x 2 6.8 x 2 11.0 x 2 2.2 8.6 x 2 9.6 x 2 59.5 x 2 9.4 5.0 x 2 6.8 x 2 11.0 x 2 2.2 14.9x 2 19.1x 2 136.0x2 9.4
9GOF 4.5 x 2 6.8 x 2 11.0 x 2 2.0 8.5 x 2 9.6 x 2 59.5 x 2 9.2 4.5 x 2 6.8 x 2 11.0 x 2 2.0 14.7x 2 19.1x 2 136.0x2 9.2
1) Fan OA is for standard unit operating at the standard pressure drop.
2) Compressor OA is referred to - room conditions: 24C, 50% RH; condensing temperature: 45C. A/W/D/H models
3) Compressor OA is referred to - room conditions: 24C, 50% RH; ext. temperature: 35C. F models
4) Compressor FLA is for the contemporary conditions of minimum evaporating pressure and maximum condensing pressures.
