Technical data and performances - air condensation - xxCA series, upward flow - 60Hz
MODEL
4PCA 4GCA 6PCA 8PCA
power supply voltage V/ph/Hz 208-230/1/60 200-230/3/60 200-230/3/60 380/3/60
PERFORMANCES
(1)
air flow m
3
/s 0.38 0.53 0.64 0.99
available head Pa 0 50 50 50
total cooling capacity kW 6.1 9.1 11.5 15.2
sensible cooling capacity kW 5.0 7.1 9.4 13.0
full absorbed power (fan and compressor) kW 2.2 3.6 3.5 4.8
compressor absorbed power kW 1.8 2.6 3.0 3.7
compressor absorbed current A 6.8 7.3 8.3 6.0
fan absorbed power kW 0.4 1.0 0.5 1.1
fan absorbed current A 1.9 3.9 2.5 4.6
SHR (Sensible Heat Ratio) - 0.81 0.79 0.82 0.86
EER (Energy Efficiency Ratio - 2.83 2.55 3.25 3.18
SPL (Sound Pressure Level)
(2)
dB(A) 49.4 51.7 54.7 50.9
FANS
quantity no. 1 1 1 1
type dd 9/9 dd 9/9 dd 10/10 dd 12/12
speed no. 3 3 3 3
motor rated power kW 0.245 0.420 0.500 0.736
poles no. 6 4 6 6
COMPRESSOR
quantity no. 1 1 1 1
type scroll
rated power for single compressor HP 1.90 2.50 3.25 4.00
refrigerant R407C R407C R407C R407C
EVAPORATING COIL
quantity no. 1 1 1 1
pipes/fins copper/aluminium
copper/treated al
uminium
fins for inch/rows no. 12/3 12/3 12/4 12/5
front surface m
2
0.33 0.33 0.33 0.50
position inclined
REFRIGERANT CONNECTIONS
gas line (pipe to be welded, o.d.) mm 12 14 14 16
liquid line (pipe to be welded, o.d.) mm 12 12 12 14
recommended diam. for refrigerant lines to the con
denser (o.d.) Gas - Liquid
mm 10-10 12-12 12-12 14-14
DIMENSIONS
length mm 750 750 750 750
depth mm 450 450 600 750
height mm 1950 1950 1950 1950
plan surface m
2
0.34 0.34 0.45 0.56
WEIGHTS
net kg
gross kg
1 ON THE FOLLOWING STANDARD CONDITIONS: standard supply [voltage  10%]; room conditions 24°C bs; 50% R.H. (17°C bu) - condensa
tion temperature: 45°C
2 Measured in the front part at 1 m height, 2 m distance, referred to free field, with working fans and compressor.
ATTENTION: the refrigerating outputs are meant after deduction of the heat taken from the fans, which must thus be added to the room load. The EER
refers only to the room unit. The unit air flow refers in standard configuration with clean class filter G3. The standard diameters of the pipings are valid
only for lengths - between the conditioner and the condensing unit - up to 30 equivalent m.
