Liebert Hiflex - Page 85

Hiflex
81-H- Version
English
Technical data and performances - dualfluid -water condensation - xxU/OH series -60Hz
MODEL 8GUH 8GOH 8LUH 8LOH
power supply voltage V/ph/Hz 380/3/60 380/3/60 380/3/60 380/3/60
PERFORMANCES
(1)
air flow m
3
/s 1.33 1.22 1.33 1.22
available head Pa 20 50 20 50
fan absorbed power kW 1.5 1.4 1.5 1.4
each fan absorbed current A 6.6 5.8 6.6 5.8
SPL (Sound Pressure Level) at 2m, f.f.
(2)
dB(A) 52.6 55.4 52.6 55.4
water temperature at the condenser inlet: 15°C - condensation temperature: 40°C
total cooling capacity kW 19.1 18.6 17.3 16.6
sensible cooling capacity kW 15.4 14.7 14.7 13.5
full absorbed power (fan and compressor) kW 5.6 5.5 5.4 5.3
compressor absorbed power kW 4.1 4.1 3.9 3.9
each compressors absorbed current A 7.2 7.2 6.9 6.9
SHR (sensible/full ratio) - 0.81 0.79 0.85 0.81
EER (Energy Efficiency Ratio) - 3.41 3.39 3.22 3.14
water flow l/s 0.20 0.19 0.18 0.17
water pressure drop kPa 4 4 3 3
water temperature at the condenser inlet: 30°C - condensation temperature: 45°C
total cooling capacity kW 18.3 17.8 16.8 16.1
sensible cooling capacity kW 15.0 14.4 14.4 13.3
full absorbed power (fan and compressor) kW 6.1 6.0 5.9 5.8
compressor absorbed power kW 4.6 4.6 4.4 4.4
each compressors absorbed current A 7.6 7.6 7.3 7.2
SHR (sensible/full ratio) - 0.82 0.81 0.86 0.83
EER (output/used energy) - 3.00 2.98 2.85 2.78
water flow l/s 0.48 0.47 0.43 0.41
water pressure drop kPa 20 19 16 15
PERFORMANCES IN DUALFLUID MODE
full refrigerating power kW 19.1 14.7 19.1 14.7
sensible refrigerating power kW 17.6 13.1 17.6 13.1
sound pressure level
(3)
dB(A) 52.1 55.0 52.1 55.0
water inlet/outlet °C 7/12 7/12 7/12 7/12
water flow l/s 0.91 0.70 0.91 0.70
water pressure drop kPa 32 21 32 21
FANS
quantity no. 1 1 1 1
type - dd 12/12 dd 12/12 dd 12/12 dd 12/12
speed no. 3 3 3 3
nominal power kW 0.736 0.736 0.736 0.736
poles no. 6 6 6 6
COMPRESSOR
quantity/type no. 1/scroll 1/scroll
nominal power for each compressor HP 5.0 5.9 5.0 5.0
refrigerant - R407C R407C R22 R22
EVAPORATING COIL CHILLED WATER
pipes/fins - copper/treated aluminium copper/treated aluminium
fins per inch/rows 12/5 12/5 12/5 12/5
front surface m
2
0.50 0.50 0.50 0.50
structure/quantity - inclined/1 inclined/1
CONDENSER
quantity/type - 1/plate 1/plate
water connections inch ½" BSP ½" BSP ½" BSP ½" BSP
DIMENSIONS
length mm 750 750 750 750
depth mm 750 750 750 750
height mm 1950 1950 1950 1950
plan surface m
2
0.56 0.56 0.56 0.56
WEIGHTS
net kg 310 310 310 310
gross kg 320 320 320 320
AT THE FOLLOWING STANDARD CONDITIONS:
1 standard supply [voltage  10%]; ambient conditions 24C bs; 50% R.H.(17C bu)
2 Measured at 1 m height and 2 m front distance, in free field, with working fans and compressor.
3 Measured at 1 m height and 2 m front distance, in free field, with working fans only.
The cooling capacities are meant after deduction of the heat taken from the fans. Therefore the heat must be added to the ambient load. EER refers
to the ambient unit only. The air flow of the units refers to the standard configuration with filter of the G3 class. The standard diameters of the pipes
only apply for lengths - between the air conditioner and the condensing unit - up to 30 equivalent m.
