Liebert Hiflex - Page 92

Hiflex
88 -C- Version
English
Technical data and performances - chilled water unit -xxUC series, downward flow -60Hz
MODEL 4LUC 6LUC 8LUC
power supply voltage V/ph/Hz 230/1/60 380/3/60 380/3/60
PERFORMANCES
(1)
air flow m
3
/s 0.64 0.90 1.37
available head Pa 20 20 20
fan absorbed power kW 1.0 0.8 1.6
fan absorbed current A 4.3 4.0 7.1
SPL (Sound Pressure Level)
(2)
dB(A) 49.1 54.7 52.3
coil inlet water temperature: 7°C; outlet water temperature: 12°C
total cooling capacity kW 7.7 13.0 18.6
sensible cooling capacity kW 7.1 11.6 17.0
water flow l/s 0.367 0.620 0.885
coil pressure drop kPa 17 16 17
total pressure drop kPa 28 28 27
SHR (sensible heat ratio) - 0.92 0.89 0.91
coil inlet water temperature: 10°C; outlet water temperature: 15°C
total cooling capacity kW 5.4 9.0 13.1
sensible cooling capacity kW 5.4 9.0 13.1
water flow l/s 0.257 0.428 0.627
coil water pressure drop kPa 10 9 10
total water pressure drop kPa 15 15 15
SHR (sensible heat ratio) - 1.00 1.00 1.00
FANS
quantity no. 1 1 1
type dd 9/9 dd 10/10 dd 12/12
speed no. 3 3 3
nominal power kW 0.420 0.500 0.736
poles no. 4 6 6
CHILLED WATER COIL
quantity no. 1 1 1
pipes/fins copper/aluminium copper/treated aluminium
fins for inch/rows no. 12/3 12/4 12/5
front surface m
2
0.33 0.50 0.50
position inclined
DIMENSIONS
length mm 750 750 750
depth mm 450 600 750
height mm 1950 1950 1950
plan surface m
2
0.34 0.45 0.56
WEIGHTS
net kg 145 175 255
gross kg 155 185 305
1 ON THE FOLLOWING STANDARD CONDITIONS:
standard supply [voltage  10%]; room conditions 24°C bs; 50% R.H. (17°C bu)
2 Measured in the front part at 1 m height, 2 m distance, referred to free field.
ATTENTION: the refrigerating outputs are meant after deduction of the heat taken from the fans, which must thus be added to the room load. The
unit air flow refers to high speed, in standard configuration with clean class filter G3.
