Hiflex
92 All Versions
English
Models 4-5 UNDER
Air flow
As REPLACEMENT of the filter G3 In ADDITION to the filter G3
[m
3
/s]
∆p G3 h=100
Filters G4 h=100 Filters F5 h=100 Filters F6 h=290 Filters F7 h=290 Filters F9 h=290
0.350 17 4 66 36 48 65
0.400 21 6 77 46 60 78
0.450 26 7 90 57 73 92
0.500 31 9 103 68 87 107
0.550 37 10 117 81 102 122
0.600 42 12 130 94 118 138
Models 6-7 UNDER
Air flow
As REPLACEMENT of the filter G3 In ADDITION to the filter G3
[m
3
/s]
∆p G3 h=100
Filters G4 h=100 Filters F5 h=100 Filters F6 h=290 Filters F7 h=290 Filters F9 h=290
0.600 25 7 87 40 58 67
0.650 29 8 96 46 65 76
0.700 33 9 106 52 73 84
0.750 37 11 116 59 81 93
Models 8-9 UNDER
Air flow
As REPLACEMENT of the filter G3 In ADDITION to the filter G3
[m
3
/s]
∆p G3 h=100
Filters G4 h=100 Filters F5 h=100 Filters F6 h=290 Filters F7 h=290 Filters F9 h=290
0.950 36 10 114 56 75 93
1.000 40 11 122 62 82 100
1.050 43 12 130 68 89 108
1.100 47 13 138 76 96 115
1.150 50 15 145 83 103 123
1.200 54 16 154 91 111 132
1.250 58 17 162 100 119 140
Models 4-5 OVER
Air flow
As REPLACEMENT of the filter G3 In ADDITION to the filter G3
[m
3
/s]
∆p G3 h=100
Filters G4 h=100 Filters F5 h=100 Filters F6 h=290 Filters F7 h=290 Filters F9 h=290
0.400 21 6 77 46 60 78
0.450 26 7 90 57 73 92
0.500 31 9 103 68 87 107
0.550 37 10 117 81 102 122
0.600 42 12 130 94 118 138
Models 6-7 OVER
Air flow
As REPLACEMENT of the filter G3 In ADDITION to the filter G3
[m
3
/s]
∆p G3 h=100
Filters G4 h=100 Filters F5 h=100 Filters F6 h=290 Filters F7 h=290 Filters F9 h=290
0.550 11 2 48 34 51 59
0.600 13 3 54 40 58 67
0.650 15 4 60 46 65 76
0.700 17 4 65 52 73 84
Models 8-9 OVER
Air flow
As REPLACEMENT of the filter G3 In ADDITION to the filter G3
[m
3
/s]
∆p G3 h=100
Filters G4 h=100 Filters F5 h=100 Filters F6 h=290 Filters F7 h=290 Filters F9 h=290
0.850 23 6 83 44 62 78
0.900 25 7 90 50 69 85
0.950 28 8 96 56 75 93
1.000 30 9 103 62 82 100
1.050 33 10 109 68 89 108
1.100 36 11 116 76 96 115
1.150 38 12 123 83 103 123
