Hiflex
94 All Versions
English
4SO A/W
5SO A/W
4LO A/W/C
5LO A/W
6SO A/W
7SO A/W
6LO A/W/C
7LO A/W
8SO A/W
9SO A/W
8LO A/W/C
9LO A/W
8LO /D/H/F
9LO /D/H/F
Air flow
Available
head
Air flow
Available
head
Air flow
Available
head
Air flow
Available
head
Air flow
Available
head
Air flow
Available
head
Air flow
Available
head
[m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa]
0.375 253 0.375 253 0.475 376 0.475 376 0.875 189 0.875 189 0.800 191
0.400 235 0.400 235 0.500 362 0.500 362 0.900 180 0.900 180 0.840 175
0.425 219 0.425 219 0.525 349 0.525 349 0.925 171 0.925 171 0.880 159
0.450 203 0.450 203 0.550 336 0.550 336 0.950 161 0.950 161 0.920 142
0.475 188 0.475 188 0.575 324 0.575 324 0.975 152 0.975 152 0.960 124
0.500 172 0.500 172 0.600 312 0.600 312 1.000 142 1.000 142 1.000 106
0.525 154 0.525 154 0.625 301 0.625 301 1.025 131 1.025 131 1.040 89
0.550 135 0.550 135 0.650 289 0.650 289 1.050 121 1.050 121 1.050 80
0.575 114 0.589 100 0.675 278 0.675 278 1.075 110 1.075 110 1.080 69
0.600 89 0.575 114 0.678 276 0.700 266 1.080 107 1.100 98 1.120 48
0.625 61 0.600 89 0.700 266 0.725 253 1.100 98 1.125 86 1.160 25
0.650 28 0.625 61 0.725 253 0.730 251 1.125 86 1.150 74 1.200 0
0.650 28 0.750 240 0.750 240 1.150 74 1.175 61
0.775 227 0.775 227 1.175 61 1.200 48
0.800 212 0.800 212 1.200 48 1.225 35
0.825 196 0.825 196 1.225 35 1.250 21
0.850 179 0.850 179 1.250 21 1.275 6
0.875 160 0.875 160 1.275 6
0.900 140 0.900 140
0.925 117 0.925 117
0.950 93 0.950 93
0.975 67 0.975 67
1.000 38 1.000 38
1.025 7 1.025 7
4SC A/W 4LC A/W 6SC A/W 8SC A/W
Air flow Available head Air flow Available head Air flow Available head Air flow Available head
[m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa] [m
3
/s] [Pa]
0.300 318 0.375 230 0.800 182 0.375 455
0.325 293 0.400 203 0.825 172 0.400 441
0.350 267 0.425 178 0.850 161 0.425 426
0.360 257 0.450 155 0.875 151 0.450 411
0.375 241 0.475 136 0.900 140 0.475 396
0.400 215 0.500 119 0.925 128 0.500 382
0.425 191 0.525 101 0.950 117 0.525 370
0.450 170 0.530 97 0.970 107 0.550 359
0.475 153 0.550 81 0.975 105 0.575 349
0.500 137 0.575 56 1.000 92 0.600 341
0.525 122 0.600 26 1.025 79 0.625 335
0.550 103 1.050 66 0.650 328
0.575 80 1.075 53 0.675 321
0.600 53 1.100 39 0.680 319
0.625 21 1.125 24 0.700 312
1.150 9 0.725 302
0.750 289
0.775 274
0.800 256
0.825 237
0.850 216
0.875 193
0.900 168
0.925 142
0.950 114
0.970 91
0.975 85
1.000 55
1.025 23
