HIMOD−C
Fig. 3 − Chilled water connections
Himod C
under
BA
A
B
B
A
55−65−80−85
27−45
150
120
140
125
125
BA
150
120
140
Right side view
(DX)
Frontal view
Right side view
(DX)
Frontal view
POS
CONNECTION
DIMENSION
POS
.
CONNECTION
27C 45−55C 65−80−85C
A Chilled water inlet 1 " female 1 ¼" female 1 ½" female
B Chilled water outlet 1 " female 1 ¼" female 1 ½" female
