HIMOD−C
Tab. 4 − Autotransformer output connections
50 Hz
autotrasformer outlet voltage
output STD graph value
au
t
o
t
ras
f
ormer ou
tl
e
t
vo
lt
age
(1)
output
connectors
bridge  fan connection  fan connection
185 E A ↔ H 185 −
200 E A ↔ G 200 −
215 E A ↔ F 215 −
230 A − 230 −
245 F A ↔ E 245 −
260 G A ↔ E 260 −
275 H A ↔ E 275 160 (156)
280 E B ↔ G 280 160 (162)
295 E B ↔ F 295 170 (167)
310 B − 310 180 (179)
325 F B ↔ E 325 180 (185)
340 G B ↔ E 340 200 (196)
355 H B ↔ E 355 200 (202)
370 E C ↔ G 370 210 (214)
385 E C ↔ F 385 220 (219)
400 C − 400 230 (231)
60 Hz
autotrasformer outlet voltage
output STD graph value
au
t
o
t
ras
f
ormer ou
tl
e
t
vo
lt
age
(1)
output
connectors
bridge  fan connection  fan connection
190 E B ↔ G 190 −
208 A − 208 −
210 E B ↔ F 210 −
230 B − 230 −
250 F B ↔ E 250 −
270 G B ↔ E 270 160 (156)
290 H B ↔ E 290 170 (167)
320 E C ↔ H 320 180 (179)
340 E C ↔ G 340 200 (196)
360 E C ↔ F 360 210 (214)
380 C − 380 220 (219)
400 F C ↔ E 400 230 (231)
420 G C ↔ E 420 −
440 H C ↔ E 440 −
460 D − 460 −
(1)  connection: fan inlet voltage = autotrasformer outlet voltage
 connection: fan inlet voltage = autotrasformer outlet voltage multiplied by 0.577
