21
HIMOD−C
Tab. 5 − Standard fan connections for HIMOD with autotransformer
50 Hz
Standard
Model
autotrasformer outlet voltage
(1)
connections output connectors bridge
25/27U C 215

E A ↔ F
35/45U C 215

E A ↔ F
50/55U C 230

A −
60/65U C 230

A −
70/80U C 230

A −
75/85U C 230

A −
90U C 260

G A ↔ E
10U C 280

E B ↔ G
12U C 260

G A ↔ E
14U C 325

F B ↔ E
25/27O C 230

A −
35/45O C 230

A −
50/55O C 230

A −
60/65O C 230

A −
70/80O C 230

A −
75/85O C 230

A −
60 Hz
Standard
Model
autotrasformer outlet voltage
(1)
connections output connectors bridge
27U C 250

F B ↔ E
45U C 250

F B ↔ E
55U C 260

G A ↔ E
65U C 260

G A ↔ E
80U C 280

E B ↔ G
85U C 280

E B ↔ G
27O C 270

G B ↔ E
45O C 270

G B ↔ E
55O C 260

G A ↔ E
65O C 260

G A ↔ E
80O C 280

E B ↔ G
85O C 280

E B ↔ G
(1)  connection: fan inlet voltage = autotrasformer outlet voltage
 connection: fan inlet voltage = autotrasformer outlet voltage multiplied by 0.577
