12
L N N L U4 L N
INPUT BYP. OUTPUT BATTERY
+
-
EXTERNAL CONNECTION APPANGMENT
SHORTING LINKS
FIG 1 : COMMON BYPASS ARRANGEMENT
INPUT BYP. OUTPUT BATTERY
+
-
FIG 2 : SEPARATE BYPASS ARRANGEMENT
