M8 / M8P Installation Manual
14 15
Zone 1
24V Mag Lock Output, Voltage Input
This zone shows a typical 24V Mag Lock application, using
a voltage input on the zone. The door can be configured via
software to unlock upon an FAI signal being received from
the FPO Power Supply.
Jumper Position: B1
Zone 2
12V Mag Lock Output, NC Relay Contact Input
This zone shows a typical 12V Mag Lock application, using
a NC relay contact as the input for the zone. The door can be
configured via software to unlock upon an FAI signal being
received from the FPO Power Supply.
Jumper Position: B2
Zone 3
12V Door Strike Output, Open Collector (transistor) Input
This zone shows a typical 12V Door Strike application, us-
ing an open collector (transistor) input on the zone. The
door can be configured via software to unlock upon an FAI
signal being received from the FPO Power Supply.
Jumper Position: B2
Zone 4
24V Door Strike Output,NO Relay Contact Input
This zone shows a typical 24V Door Strike application, us-
ing a NO relay contact as the input for the zone. The door
can be configured via software to unlock upon an FAI signal
being received from the FPO Power Supply.
Jumper Position: B1
Zone 5
12V Reader Power, no control input
This zone shows continuous 12V auxiliary power for pow-
ering a device such as a reader. The output can be config-
ured via software to remove power upon an FAI signal being
received from the FPO Power Supply.
Jumper Position: B2
Zone 6
24V Door Holder Power, no control input
This zone shows continuous 24V auxiliary power for pow-
ering devices such as door holders. The output can be con-
figured via software to remove power upon an FAI signal
being received from the FPO Power Supply.
Jumper Position: B1
Zone 7
12V REX Power, no control input
This zone shows continuous 12V auxiliary power for pow-
ering devices such as REX devices. The output can be con-
figured via software to remove power upon an FAI signal
being received from the FPO Power Supply.
Jumper Position: B2
Zone 8
24V Camera Output, no control input
This zone shows continuous 24V auxiliary power for pow-
ering devices such as PTZ Cameras. The output can be con-
figured via software to remove power upon an FAI signal
being received from the FPO Power Supply.
Jumper Position: B1
M8/M8P Application Example
This section shows various input and output types all wired to a single M8 board. These are for example purposes only
and your exact application may not be shown.
