LifeSafety Power M8P

M8 / M8P Installation Manual
14 15
FlexIO
BR B2 B1
FAULTFAULT
B1 24V
B2 12V
BR
BL
NC Contact
+12/24V Voltage IN
NO Contact
No Connection
Open Collector (Transistor) In
IN1 IN2 IN3 IN4 IN5 IN6 IN7 IN8
A A A AB B B B A B A B A B A B
1 2 3 4 5 6 7 8
B2 B2 B2 B2
B1 B1 B1 B1
READER
12V
DOOR
STRIKE
24V
+
–
+
–
MAG
LOCK
24V
MAG
LOCK
12V
DOOR
STRIKE
12V
+
–
+
–
–
+
–
CAMERA
24V
–
–
+
DOOR
HOLDER
24V
–
+
REX
12V
–
–
+
INPUTS
1 2 3 4 5 6 7 8
A B A B A B A B A B A B A B A B
OUTPUTS
– +– +– +– +– +– +– +– +
M8/M8P Application Example
