1. Fix the Seat (33) to the Vertical Seat
Post (pt.36) as shown, with the flat
washer (34) and the nylon nut (35).
2. Insert the vertical Seat Post (36) into
the main frame (18) and line up the
holes.
3. Secure the saddle in position with the
Adjustment Knob (31). The correct
height for the seat can be adjusted
after the bike is fully assembled.
connect the sensor A1&A2 as shown in
FIG.2,
4. Install the Handlebar Post (40) onto the
main frame (18) with arc washer (16)
and M8 Domed Nut (pt.17).
