Lifetime 90192 - Hardware Identifier (Part 1); Pole Assembly Hardware Details; Pole to Base Hardware Details; Backboard to Rim Hardware Details

11
HARDWARE IDENTIFIER
0/,%!33%-",9(!2$7!2%
Hardware shown at Actual Size
"!#+"/!2$4/2)-!33%-",9(!2$7!2%
Hardware shown at Actual Size
0/,%4/"!3%!33%-",9(!2$7!2%
Hardware shown at Actual Size
ADS (x2)
1/4” x 3/4” Screw
ABZ (x2)
Xv3ELF4APPING3CREW
ABB (x2)
3/8” Centerlock Nut
!!& (x2)
3/8” Washer
ABE (x2)
3/8” x 4” Hex Bolt
ABR (x2)
1/2” x 3.41” Spacer
BTS (x1)
1/4” Barrel Nut
AAE (x2)
5/16” x 1” Hex Bolt
AAO (x2)
5/16” Nylock Nut
BZP (x1)
1/4” x 3 1/2” Shoulder Bolt
ABD (x4)
5/16” Washer
AAS (x2)
1/4” x 2 3/4” Hex Bolt
ABC (x2)
5/16” x 1 1/4” Carriage Bolt
CIH (x2)
Domed Counter
sink Washer
