BACKBOARD TO POLE ASSEMBLY
HARDWARE REQUIRED
PARTS REQUIRED
TOOLS REQUIRED
SEC

Parts shown at 10% of Actual Size
Hardware shown at Actual Size
!!8 (x4)
1/2” Centerlock Nut
ABL (x4)
.69” x .59” Black Spacer
Rubber Mallet
v7RENCH(x2)
AAD (x4)
1/2” x 7 1/16” Hex Bolt
(Not actual length)
ABN (x4)
1/2” x 1/8” Spacer
AKC (x2)
Short Extension Arm
30 1/16”
AKB (x2)
,ONG%XTENSION!RM
21 1/8”
7 1/16”
