HANDLE ASSEMBLY
HARDWARE REQUIRED
SEC
5
ADR (x4)
#7 x 3/8”
Phillips Screw
AQH (x2)
Trigger Spring
CNI (x4)
5/16” x 1” Pan Head Screw
AAC (x1)
5/16” x 1 3/4” Hex Bolt
AAN (x1)
5/16” Cap Nut
7”
(Not actual length)
!!8 (x1)
1/2” Centerlock Nut
ABO (x2)
1/2” x 1” Poly Spacer
ABB (x1)
3/8” Centerlock Nut
AAD (x1)
1/2” x 7 1/16” Hex Bolt
7 1/16”
(Not actual length)
AAZ (x1)
3/8” x 7” Hex Bolt
Hardware shown at Actual Size
AZP (x2)
1/4” Nylock Nut
CNE (x1)
4WO(EAD3NAP"UTTON
CNH (x2)
vXv
5.#!3CREW
!!* (x4)
v(EX4.UT
