Lifetime 90192 - Pole to Base Assembly; Hardware Required for Pole to Base Assembly; Parts Required for Pole to Base Assembly; Tools Required for Pole to Base Assembly

22
21 3/4 ”
!*$ (x1)
1/2” x 21 3/4” Axle
38 ”
!*- (x1)
Base
ALI (x2)
Pole Brace
AMU (x2)
Wheel
Parts shown at 10% of Actual Size
Parts shown at 25% of Actual Size
POLE TO BASE ASSEMBLY
HARDWARE REQUIRED
PARTS REQUIRED
TOOLS REQUIRED
SEC
2
Part shown at 5% of Actual Size
Hardware shown at Actual Size
AAE (x2)
5/16” x 1” Hex Bolt
AAO (x2)
5/16” Nylock Nut
ABD (x4)
5/16” Washer
7RENCH (x2)
!*. (x1)
Base Cap
Rubber Mallet
BTS (x1)
1/4” Barrel Nut
BZP (x1)
1/4” x 3 1/2” Shoulder Bolt
v!LLEN7RENCH(x2)
